OMEGA CNI833C4EITDC digital panel meter
The CNi8 series is a high-accuracy, programmable digital panel meter with a large color-changing LED display, capable of monitoring temperature, process, and strain signals. It supports multiple input types including thermocouples, RTDs, voltage, current, load cells, and pressure transducers, with built-in excitation. Ideal for industrial applications, the meter features customizable alarm and control outputs, Ethernet connectivity, and advanced programming options. Designed for robust performance, it ensures precise measurements with ±0.5°C accuracy for temperature and 0.03% for process readings, making it suitable for diverse control and monitoring tasks.
OMEGA CNI833C4EITDC digital panel meter Specifications:
- Display: 4-digit 9-segment LED with RGB color change
- Sizes: i/8 (96x48 mm), i/16 (48x48 mm), i/32 (48x25.4 mm)
- Power Supply: 90-240 Vac (10%), 110-300 Vdc; optional 24 Vac/dc
- Input Types: Thermocouple, RTD, voltage, current, strain gauges
- RTD Accuracy: ±0.1°C (RTD-1N), ±0.3°C (RTD-2N)
- Thermocouple Types: J, K, T, E, R, S, B, C, N, L
- Process Voltage Range: 0-100 mV, 0-1 V, 0-10 V; Current Range: 0-20 mA
- Built-in Excitation: 24 Vdc @ 25 mA (RTD), 5 Vdc or 10 Vdc for strain
- Measurement Stability: RTD: 0.04°C/°C, TCs: 0.05°C/°C
- Accuracy: Temperature ±0.5°C, Process ±0.03% of reading
- Communications: Ethernet (TCP/IP), RS232, RS485 with MODBUS, ASCII
- Outputs: Control relays, SSRs, analog retransmission (0-10 V or 0-20 mA)
- Environmental Range: 0-55°C, 90% RH, NEMA/IP66 protection options available
- Dimensions: 96x48 mm, 48x48 mm, or 48x25.4 mm panel cutouts
- Certifications: UL, C-UL, CE, FM (temperature units only)
Buy the Buy Omega CNi8 Part Number CNI833C4EIT Online
Discover the Omega CNi8 digital panel meter, designed for precise temperature, process, and strain measurements with a vibrant color display. Its universal inputs support thermocouples, RTDs, voltage, current, and strain sensors, making it perfect for diverse industrial applications. Built-in excitation and flexible outputs, including relays, SSRs, and analog retransmission, enable seamless control and alarming. Its Ethernet and serial communication options facilitate remote monitoring, ensuring reliable operation in demanding environments. Upgrade your system for optimal performance and control today.
Buy Omega CNi8 now and experience unmatched accuracy, versatile inputs, and advanced control features for industrial monitoring.
Frequently Asked Questions
Where can I buy OMEGA CNI833C4EITDC?
You can click on the BUY or RFQ button to purchase CNI833C4EITDC from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CNI833C4EITDC?
You can download the CNI833C4EITDC datasheet or visit the OMEGA website for support.
Who is the manufacturer of CNI833C4EITDC?
OMEGA
