OMEGA DP25BS Digital Panel Meter
The DP25B-S is an economical, programmable digital panel meter designed for accurate measurement of voltage, current, or bridge sensors. It features a 4-digit LED display with selectable color options—red, amber, or green—and includes built-in sensor excitation, front-panel tare, and peak hold functions. Its precise accuracy of ±0.03% of reading ensures reliable readings. The device supports various input ranges and excitation voltages, with optional dual alarm relays and scalable analog outputs for enhanced monitoring. Its rugged design meets NEMA 4 (IP65) standards, suitable for industrial environments, with a fast conversion rate of 3 readings per second.
OMEGA DP25BS Digital Panel Meter Specifications:
- Accuracy: ±0.03% of reading, +1 count
- Display: 4-digit, 21 mm high LED in red, amber, or green, -1999 to 9999 counts
- Input Ranges: 0 to 100 mV, 0 to 10 V, 0 to 20 mA, 4 to 20 mA, user selectable
- Sensor Excitation: 24 V @ 25 mA, 12 V @ 50 mA, 5 V @ 60 mA, 10 V @ 120 mA
- Power Supply: 115 Vac (standard) or 230 Vac (optional); 50/60 Hz, 9.5-11.5 W
- Operating Temp: 0°C to 50°C; Storage: -40°C to 85°C
- Humidity: 90% at 40°C (non-condensing); Dielectric Strength: 2500 V transient
- Relays: Dual 250 Vac, 5 A, SPDT; Analog Output: 0-10 V or 4-20 mA, scalable
- Dimensions: Bezel 96 W x 48 H x 20 mm D, Panel Cutout 92 W x 45 H mm, Behind Panel 152 mm deep
- Connectivity: Supports built-in sensor excitation, front panel tare, peak hold functions
- Standards: NEMA 4 (IP65), EN 61010 dielectric strength
Buy the Omega DP25B-S – Reliable Digital Panel Meter for Industrial Applications
Order the Omega DP25B-S digital panel meter online today for high-precision voltage, current, and bridge sensor measurements. It features a programmable LED display in red, amber, or green, with tare, peak hold, and optional alarm relays. Its robust design complies with NEMA 4 (IP65) standards, making it suitable for harsh industrial settings. With various input ranges, excitation options, and scalable analog outputs, the DP25B-S ensures reliable operation, fast response time, and easy integration into your control systems. Perfect for automation and process monitoring applications.
Get Omega DP25B-S today—built for accurate measurement and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy OMEGA DP25BS?
You can click on the BUY or RFQ button to purchase DP25BS from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part DP25BS?
You can download the DP25BS datasheet or visit the OMEGA website for support.
Who is the manufacturer of DP25BS?
OMEGA
