TRACO POWER TDN52422WI DC/DC Converter
The TDN 5WI Series is a high-performance 5 Watt DC/DC converter designed with an ultra-compact cubical package measuring only 13.2 x 9.1 x 10.2 mm. It features 1600 VDC isolation, fully regulated outputs, remote On/Off, and short circuit protection, making it ideal for space-constrained applications. Operating between -40°C and +75°C with derating, it meets IEC/EN 62368-1 standards. Suitable for industrial and embedded systems, it offers wide input voltage ranges, low ripple, and excellent efficiency up to 84%. The robust design guarantees reliable operation in various environments.
TRACO POWER TDN52422WI DC/DC Converter Specifications:
- Dimensions: 13.2 x 9.1 x 10.2 mm
- Isolation Voltage: 1600 VDC
- Operating Temperature Range: -40°C to +75°C, derating above 50°C
- Input Voltage Range: Wide (4:1 ratio), models vary (3.3V, 5V, 9V, 12V, 15V, 24V, etc.)
- Output Power: 5 Watts
- Output Voltage: Various options (3.3V to 15V)
- Maximum Output Current: 210 mA to 1 A depending on model
- Efficiency: up to 84%
- Ripple and Noise: 50-75 mVp-p (at 20 MHz bandwidth)
- Short Circuit Protection: Yes, automatic recovery
- Start-up Time: ~10 ms
- Isolation Resistance: >1 GΩ at 500 V
- Housing Material: UL 94 V-0 rated FR4, silicone potting
- Soldering Temperature: 260°C / 6 s max.
- EMC Compliance: EN 61000-4 series, ESD, radiated immunity
Buy the Traco Power Series TDN 5WI DC/DC Converter: TDN52422WI
Order the Traco Power TDN52422WI online today and benefit from a compact, highly efficient 5 Watt DC/DC converter with 1600VDC isolation. Its robust design supports wide input voltage ranges, operates from -40°C to +75°C, and features automatic short circuit protection. Ideal for industrial, embedded, and space-constrained applications, it ensures reliable performance even in challenging environments. Enjoy fast delivery, secure checkout, and the assurance of high quality with every purchase. Upgrade your power solution now.
Buy Traco Power TDN52422WI now and experience unmatched reliability, high efficiency, and space-saving design for your power conversion needs.
Frequently Asked Questions
Where can I buy TRACO POWER TDN52422WI?
You can click on the BUY or RFQ button to purchase TDN52422WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TDN52422WI?
You can download the TDN52422WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TDN52422WI?
TRACO POWER
