TRACO POWER TMH2415S DC/DC Converter
The TMH Series is a compact, high-efficiency 2-Watt isolated DC/DC converter featuring SMD construction with single and dual-output options. Designed for space-critical applications, these converters offer 1000 VDC isolation, RoHS compliance, and reliability tested with 100% burn-in. They deliver adjustable output voltage, low ripple, and operate over a wide temperature range. Ideal for industrial and electronic equipment, these compact modules ensure high performance with an efficiency up to 83% and robust environmental specifications.
TRACO POWER TMH2415S DC/DC Converter Specifications:
- Power: 2 Watts
- Input Voltage: 5 VDC, 12 VDC, 24 VDC (±10%)
- Output Voltage: 5 VDC, 12 VDC, 15 VDC (adjustable ±3%)
- Output Current Max: 400 mA (5V), 165 mA (12V), 130 mA (15V)
- Efficiency: up to 83%
- Isolation Voltage: 1000 VDC
- Isolation Resistance: > 1000 MΩ
- Storage Temperature: -40°C to +125°C
- Operating Temperature: -40°C to +85°C
- Ripple: 75 mV pk-pk (5V input), 150 mV pk-pk (12/24V input)
- Dimensions: 19.5 x 15.0 x 10.1 mm
- Material: UL 94 V-0 plastic case
- Weight: 27g
- Humidity: 95% non-condensing
- MTBF: > 2 million hours
- Certifications: RoHS, UL compliant
- Other features: Overcurrent, short-circuit protection, reflected ripple reduction
- Frequency: 80 kHz typical
Buy the Traco Power Series TMH DC/DC Converter: TMH2415S
Enhance your electronic projects with the TMH Series 2 Watt isolated DC/DC converter from Traco Power. Featuring compact design, wide temperature range, RoHS compliance, and high efficiency up to 83%, this converter provides reliable power conversion for industrial, automation, and embedded applications. With 1000 VDC isolation and adjustable outputs, it ensures safety, flexibility, and robust operation even in space-constrained environments. Trust Traco Power’s quality for your critical power needs and purchase online for quick, secure delivery.
Buy Traco Power TMH2415S now and experience unmatched reliability and performance in compact high-efficiency DC/DC conversion.
Frequently Asked Questions
Where can I buy TRACO POWER TMH2415S?
You can click on the BUY or RFQ button to purchase TMH2415S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMH2415S?
You can download the TMH2415S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMH2415S?
TRACO POWER
