TRACO POWER TEN302411 DC/DC Converter
The TEN 30 series is a highly efficient, compact DC/DC converter offering 30 Watts of power in a sealed metal housing with dimensions of 50 x 25 mm. Designed for industrial and communication applications, it features high efficiency up to 91%, an extended temperature range from -40°C to +85°C, and various models with single and dual outputs. It includes features like external on/off control, adjustable output voltage, over-temperature, and under-voltage protection. Suitable for space-constrained environments, these modules provide reliable, regulated, and isolated power supplies for demanding systems.
TRACO POWER TEN302411 DC/DC Converter Specifications:
- Power Rating: 30 W
- Dimensions: 50 x 25 x 10.2 mm
- Housing: Sealed metal with isolated baseplate
- Input Voltage Range: 2:1 wide range (e.g., 12 V, 24 V, 48 V options)
- Output Voltage: Regulated, adjustable with external resistor
- Maximum Output Current: up to 8 A depending on model
- Efficiency: Up to 91%
- Operating Temperature: -40°C to +85°C
- Isolation Voltage: 1500 VDC input to output
- Protection: Short circuit, over-temperature, under-voltage
- Certifications: UL 60950-1
- Features: External on/off, transient response, high EMI immunity
- MTBF: 550,000 hours
- Switching Frequency: 30 kHz
Buy the Buy TracoPower DC/DC Converter Part Number TEN 30 Series Online
Purchase the TracoPower TEN 30 series DC/DC converter online today to enjoy high efficiency, reliable regulation, and wide temperature operation. Ideal for industrial, communications, and embedded systems where space is limited. These compact modules feature adjustable output voltages, built-in protection, and a sealed metal housing, ensuring durability and safety. Perfect for mobile power supplies or decentralized systems, they deliver 30 Watts of power with efficiencies up to 91%, supporting demanding applications with confidence. Order now for fast delivery and long-term performance.
Get TracoPower TEN 30 series DC/DC converter today—designed for high efficiency and reliable power in tight spaces.
Frequently Asked Questions
Where can I buy TRACO POWER TEN302411?
You can click on the BUY or RFQ button to purchase TEN302411 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN302411?
You can download the TEN302411 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN302411?
TRACO POWER
