TRACO POWER THM60511WI DC/DC Converter
The THM 6-0511WI is a high-performance, regulated 6W DC/DC converter designed with reinforced input/output isolation to meet medical safety standards for MOPP. It accepts an input voltage range of 4.5 to 9V DC and provides a 5V DC output. The converter features a wide 4:1 input voltage range, built-in EMI filter to meet EN55022 Class A standards, and uses high-quality components for reliable operation across temperatures from -40°C to 88°C at full load. It offers an isolation rating of 5000 VAC RMS (with a working voltage of 250 VAC RMS) and has an efficiency of approximately 86%. Suitable for use in automotive, industrial, medical, and test and measurement applications.
TRACO POWER THM60511WI DC/DC Converter Specifications:
- Input Voltage Range: 4.5 to 9 V DC
- Output Voltage: 5 V DC
- Output Current Max: 600 mA
- Efficiency: ≈86%
- Isolation Voltage: 5000 VAC RMS, rated for 250 VAC RMS working
- Temperature Range: -40°C to 88°C at full load
- Ripple and Noise: 40 mVp-p with filter cap
- Protection: Over load at 150% rated, automatic recovery short circuit, over voltage
- EMC Compliance: EN 55022 Class A, IEC 60601-1-2
- Surge Voltage: up to 100 V max.
- Leakage Current: < 2 μA
- Dimensions: Compact DIP-24 plastic case, weight approx. 14 g
- Safety Standards: IEC/EN/ES 60601-1 for MOPP, ISO 13485 quality systems
- Start-up Voltage: 9 VDC or lower
- Humidity: 5% to 95% non-condensing
- Thermal Impedance: 18°C/W
- Vibration & Shock Resistance: MIL-STD-810F
Buy the Buy Traco Power DC/DC Converter Part Number THM60511WI Online
Discover the power of the Traco Power THM 6-0511WI, a 6-watt medical-grade DC/DC converter with reinforced isolation and wide input voltage range. Its high efficiency of approximately 86% ensures minimal energy loss, making it ideal for demanding applications like medical equipment, industrial systems, automotive electronics, and test measurement devices. Certification according to IEC/EN/ES 60601-1 guarantees safety, while the robust design provides reliable operation from -40°C to 88°C. Purchase online today for a dependable, compact solution.
Buy Traco Power THM 6-0511WI now and experience reliable medical-grade isolation, high efficiency, and durable performance in your applications.
Frequently Asked Questions
Where can I buy TRACO POWER THM60511WI?
You can click on the BUY or RFQ button to purchase THM60511WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM60511WI?
You can download the THM60511WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM60511WI?
TRACO POWER
