TRACO POWER TEN30523 DC/DC Power Converter
The TEN 3 series are high-efficiency, 3 Watt DC/DC converters designed for industrial and communication applications. They feature UL60950-1 safety standard compliance, wide 2:1 input ranges, and operate reliably from -40°C to +85°C. With full SMD design, internal filtering per EN 55022-A and FCC level A, and short circuit protection, these converters ensure high reliability with an MTBF of over 1.1 million hours. They offer isolation of 1500 VDC, compact construction, and are ideal for space-constrained environments demanding robust power solutions.
TRACO POWER TEN30523 DC/DC Power Converter Specifications:
- Input Voltage Range: 3.3 VDC to 48 VDC with models for 5 V, 12 V, 24 V, and 48 V inputs
- Output Power: 3 Watt
- Efficiency: up to 84%
- Operating Temperature: -40°C to +85°C
- Isolation Voltage: 1500 VDC
- Ripple and Noise: 50 mVpk-pk at 20 MHz bandwidth
- MTBF: >1.1 million hours
- Short Circuit Protection: Automatic recovery
- Protection: Inbuilt reverse voltage protection of 1.0 A
- Regulation: Input variation up to 0.5%, load variation 10-100%
- Dimensions: Compact, specific sizes vary by model
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, CSA
- Switching Frequency: ~300 kHz (PWM)
- Case Material: Non-conductive FR4, UL 94V-0 rated epoxy potting
- Weight: 12 grams
- Soldering Temperature: Max 265°C for 10 seconds
- Humidity Tolerance: Up to 95% RH non-condensing
Buy the TRACOPOWER TEN 3 Series – Reliable 3W Power Supply for Industrial Applications
Discover the TRACOPOWER TEN 3 Series 3 Watt DC/DC converters, engineered for demanding industrial and communication systems. These compact, high-efficiency modules offer wide input voltage ranges from 3.3 V to 48 V, with operating temperatures from -40°C to +85°C, making them ideal for rugged environments. Featuring UL606950-1 certification, internal filtering, and short circuit protection, they ensure reliable, safe, and durable power solutions. Available for online purchase now, providing bandwidth for your automation and communication projects with confidence.
Get TRACOPOWER TEN 3 Series 3 Watt converter today—optimized for industrial reliability and extended temperature operation.
Frequently Asked Questions
Where can I buy TRACO POWER TEN30523?
You can click on the BUY or RFQ button to purchase TEN30523 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN30523?
You can download the TEN30523 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN30523?
TRACO POWER
