TRACO POWER TMM24215 Medical Power Module
The TMM 24 Series offers fully encapsulated 24 Watt AC/DC power modules designed for medical, industrial, transportation, and equipment applications. Featuring low no-load power consumption below 0.3W, high efficiency, and excellent EMI/EMC characteristics, these modules are suitable for operating temperatures from -40°C to +65°C with derating up to 75°C at 50% load. They provide dual safety isolation (2x MOPP) according to latest standards, protection against over-temperature, overload, and short circuits, with certifications including UL 60601-1, IEC 60950-1, and UL 508 chassis mount versions. Compact, reliable, and environmentally compliant, they are ideal for demanding electronic systems.
TRACO POWER TMM24215 Medical Power Module Specifications:
- Output Power: 15 W to 24 W depending on model
- Input Voltage: 100-240 VAC, 85-264 VAC (AC range), 120-370 VDC (DC range)
- Input Frequency: 47 ~ 440 Hz
- Efficiency: Up to 85%
- No Load Power Consumption: <0.3W
- Isolation Voltage: 4000 VAC (Input/Output)
- Operating Temperature: -40°C to +65°C (up to 75°C with derating)
- Cooling: Natural convection
- Humidity: 95% non-condensing
- Altitude: 5000 m
- Protection: Over-temperature, overload, short circuit, auto recovery
- Safety Certifications: UL 60601-1, IEC 60950-1, UL 508, ANSI/AAMI ES 60601-1
- Material: UL 94V-0 rated plastic resin
- Dimensions: Approximate length 62.0 mm, weight 137-147 g
- EMC Compliance: EN 55022 Class B, FCC Part 15 Level B
- Standards: IEC/EN 61000 series immunity, safety class II
- Certifications: UL, IEC/EN standards
- Temperature Range: -40°C to +80°C (operation), -40°C to +95°C (storage)
Buy the Traco Power Series TMM 24 AC/DC Power Modules: TMM24215
Secure your systems with the Traco Power TMM24215 24 Watt power module, featuring dual safety isolation, high efficiency, and low no-load power consumption below 0.3W. Designed for demanding medical, industrial, and transportation applications, these compact modules operate reliably from -40°C to +65°C, with protection against over-temperature, overload, and short circuits. Certified to UL 60601-1, IEC 60950-1, UL 508, they meet strict safety and EMC standards. Easy to install and environmentally compliant, they ensure your equipment performs flawlessly under varying conditions. Buy online today for dependable power solutions.
Buy Traco Power TMM24215 24 Watt medical and industrial power modules now and experience unmatched reliability and performance.
Frequently Asked Questions
Where can I buy TRACO POWER TMM24215?
You can click on the BUY or RFQ button to purchase TMM24215 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMM24215?
You can download the TMM24215 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMM24215?
TRACO POWER
