TRACO POWER THI30522 Medical Power Converter
This medical-grade DC/DC converter provides high isolation and reinforcement suitable for healthcare devices and industrial controls, ensuring safety and efficiency. Encapsulated in a DIP-24 package, it features reinforced insulation, input filter, low leakage current, short circuit protection, and high efficiency up to 64%. Designed to meet IEC/EN 60601-1 and IEC 60950-1 standards, it operates from 5 VDC to 24 VDC inputs with outputs ranging from 15 VDC to 15 VDC, offering reliability in medical and industrial systems with a 3-year warranty.
TRACO POWER THI30522 Medical Power Converter Specifications:
- Input Voltage Range: 5 VDC, 12 VDC, 24 VDC
- Output Voltage: 15 VDC, 12 VDC, 5 VDC, 24 VDC
- Output Current Max: 600 mA to 250 mA depending on model
- Efficiency: Up to 64%
- Isolation Voltage: 4000 VACrms, rated for 300 Vrms working
- Isolation Capacitance: 20 pF typ.
- Leakage Current: 2 pA at 240 VAC
- Operating Temp: -40°C to +75°C
- Case Material: UL 94-0 rated plastic
- Dimensions: Compact DIP-24 package
- Switching Frequency: 25-60 kHz
- Certifications: IEC/EN 60601-1, IEC 60950-1, RoHS
- Soldering Temp: Max 260°C for 10 seconds
- Humidity: Up to 95% relative humidity
- Altitude: Up to 4000 m
Buy the Traco Power Series THI 3 Medical Isolated Converter: THI30522
Purchase your Traco Power Series THI 3 medical DC/DC converter online today and benefit from high isolation, reinforced insulation, and reliable operation for healthcare and industrial applications. Designed to meet strict medical safety standards, this converter offers excellent efficiency, low leakage current, and short circuit protection. With a compact DIP-24 package and certified safety compliance, it ensures optimal performance for medical instrumentation and industrial controls. Get your high-quality, dependable power solution now and enhance your project’s safety and reliability.
Order your Traco Power Series THI 3 medical DC/DC converter today and ensure your healthcare devices meet the highest safety standards with reliable performance.
Frequently Asked Questions
Where can I buy TRACO POWER THI30522?
You can click on the BUY or RFQ button to purchase THI30522 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THI30522?
You can download the THI30522 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THI30522?
TRACO POWER
