TRACO POWER TEN31215N DC-DC Converter
The TEN 3-1215N from TracoPower is a 3W single-output DC-DC converter housed in a 24-pin DIP package. Designed as a drop-in replacement for common TEN 3 series converters, it features an up-to-date design that reduces costs without compromising reliability or functionality. The converter offers a wide 2:1 input voltage range from 9V to 18V DC, with an input current of 35mA at no load. It provides a stable 24V DC output with a maximum output current of 125mA and an efficiency of 84%. This device includes comprehensive EMC filtering to meet EN 55022, FCC Level A standards without external components, and offers increased electromagnetic compatibility immunity. It also features an extended operating temperature range from -40°C to +85°C, continuous, automatic recovery short circuit protection, and no minimum load requirement. The output has high isolation with 1500VDC isolation voltage, greater than 1000 MΩ input/output resistance at 500VDC, and a maximum voltage set accuracy of ±2%. The converter complies with multiple safety standards including UL 60950-1, IEC 60950-1, and others. It is approved for industrial and power management applications. Physical dimensions are 20.3mm x 10.2mm x 31.8mm, with a minimum switching frequency of 90kHz.
TRACO POWER TEN31215N DC-DC Converter Specifications:
- Input Voltage Range: 9V to 18V DC
- Output Voltage: 24V DC
- Output Current Max: 125mA
- Efficiency: 84%
- Isolation Voltage: 1500VDC
- Isolation Resistance: >1000 MΩ at 500VDC
- No Load Input Current: 35mA (12V models)
- Ripple & Noise: 70mVPK-PK (20 MHz BW)
- Operating Temperature: -40°C to +85°C
- Dimensions: 20.3mm x 10.2mm x 31.8mm
- Switching Frequency: ≥90kHz
- Regulation: ±2% max.
- Short Circuit Protection: Automatic Recovery
- Safety Standards: UL 60950-1, IEC 60950-1
- Environmental Standards: RoHS, Reach
- Pin Material: Copper alloy with gold plating
Buy the TracoPower TEN 3-1215N – Reliable DC-DC Converter for Industrial Applications
Enhance your industrial power solutions with the TracoPower TEN 3-1215N DC-DC converter. Offering 3W of power with high efficiency and extended temperature operation, it ensures reliable voltage regulation in demanding environments. Its high isolation voltage of 1500VDC and compliance with UL and IEC safety standards make it suitable for a variety of industrial, automation, and power management applications. Easy to install, with no minimum load requirement, this converter's compact size and robust design deliver dependable, long-lasting performance—order online today for quick, secure delivery.
Get TracoPower TEN 3-1215N today—built for precision, high isolation, and durability in demanding power conversion tasks.
Frequently Asked Questions
Where can I buy TRACO POWER TEN31215N?
You can click on the BUY or RFQ button to purchase TEN31215N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN31215N?
You can download the TEN31215N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN31215N?
TRACO POWER
