TRACO POWER TIM351212 DC/DC Converter
The TIM 3.5 series are high-performance, regulated DC/DC converters offering 3.5 watts with reinforced I/O-isolation aligned with medical safety standards. Suitable for demanding applications such as medical equipment, transportation, and industrial control, these converters feature wide input voltage ranges (from 4.5 VDC to 75 VDC), efficiency up to 83%, and operate within a temperature range of -55°C to +125°C with derating. They include features like low leakage current, short circuit protection, and compliance with IEC/EN 60601-1 safety standards, ensuring reliable, safe power solutions for medical and industrial devices.
TRACO POWER TIM351212 DC/DC Converter Specifications:
- Input Voltage Range: 4.5 VDC to 75 VDC
- Output Voltage: 12 VDC (±1%)
- Output Current Max: 290 mA
- Efficiency: Up to 83%
- Isolation Voltage: 5000 VACrms, rated for 250 VACrms working voltage
- Operating Temperature: -55°C to +125°C with derating
- Humidity: 5% to 95% relative humidity (non-condensing)
- Dimensions: Length 16.0 mm, Width 11.0 mm, Height 6.0 mm
- Soldering Temperature: Max 265°C for 10 sec
- Switching Frequency: Minimum 100 kHz
- Leakage Current at 240 VAC: 2 μA max
- Mechanical Case Material: Non-conductive black plastic
- Potting Material: Silicone (UL94-V0)
- Certifications: IEC/EN 60601-1, UL, RoHS Compliant
Buy the Traco Power Series TIM3.5 12V DC/DC Converter: TIM351212
Enhance your medical and industrial systems with the high-quality Traco Power TIM351212 DC/DC converter. This 3.5-watt device offers wide input voltage compatibility from 4.5 VDC to 75 VDC, ensuring versatile integration. With efficiency up to 83%, reinforced isolation of 5000 VAC, and compliance with IEC/EN 60601-1 safety standards, it guarantees reliable and safe power delivery. Its compact size, low leakage current, and robust construction make it ideal for demanding environments such as medical devices, transportation, and industrial control systems. Purchase online today for a dependable power solution.
Get Traco Power TIM351212 today—built for precision, safety, and long-lasting durability in medical and industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER TIM351212?
You can click on the BUY or RFQ button to purchase TIM351212 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TIM351212?
You can download the TIM351212 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TIM351212?
TRACO POWER
