TRACO POWER TEN32422WIN DC/DC Converter
The TEN 3WIN Series by Traco Power is a 3-watt DC/DC converter designed for demanding applications requiring high reliability and extended temperature ranges. Featuring an ultra-wide 4:1 input range, internal filtering to meet EN 55032 Class A standards, and an industrial-grade isolation voltage of up to 3,000 VDC, these converters are ideal for cost-sensitive, space-constrained environments. With an operating temperature range from -40°C to 85°C, high efficiency up to 82%, and a compact DIP-24 package, they are perfect for industrial automation, control systems, and instrumentation.
TRACO POWER TEN32422WIN DC/DC Converter Specifications:
- Input voltage range: 24 VDC (-9 V min.), 48 VDC (-18 V min.)
- Output voltage: 12 VDC
- Output current max.: 250 mA
- Efficiency max.: 82%
- Isolation voltage: 1500 VDC or 3000 VDC (model dependent)
- Operating temperature: -40°C to +85°C
- Start-up voltage: 9.0 VDC (24 V models), 18 VDC (48 V models)
- Dimensions: 22.86 mm x 15.24 mm x 12.7 mm, DIP-24 package
- Weight: 12.8 g
- Soldering temperature: 260°C for 10 seconds
- UL, cUL, IEC/EN 60950-1, CSA certified
- Ripple and noise: 70 mVpk-pk (20 MHz bandwidth)
- MTBF: >1 million hours
- Shock and vibration resistant, compliant with safety standards
- Switching frequency: 90 kHz minimum
Buy the Buy Traco Power DC/DC Converters Part Number TEN32422WIN Online
Order the Traco Power TEN32422WIN DC/DC converter online today. This 3-watt power supply offers a wide input range, extended temperature operation from -40°C to 85°C, high efficiency, and reliable electrical isolation up to 3000 VDC. Perfect for industrial, automation, and instrumentation applications, its compact DIP-24 package and internal filtering meet stringent EMC standards without external components. Enhance your system's performance and ensure long-term dependability by purchasing this robust, UL-listed power converter online now.
Buy Traco Power TEN32422WIN now and experience unmatched reliability and performance for industrial automation and control systems.
Frequently Asked Questions
Where can I buy TRACO POWER TEN32422WIN?
You can click on the BUY or RFQ button to purchase TEN32422WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN32422WIN?
You can download the TEN32422WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN32422WIN?
TRACO POWER
