TRACO POWER TEN34821WIN Dual Output DC-DC Converter
The TEN 3-4821WIN by TracoPower is a 3W dual-output DC-DC converter housed in a compact 24-pin DIP package. Designed as a drop-in replacement for the TEN 3WI series, it features an ultra-wide input voltage range from 18VDC to 75VDC, with an input current of 20mA at no load. It offers an ±5VDC output with up to ±250mA output current and an 80% efficiency. Built for reliability, it includes automatic short-circuit protection, meets EMC standards without external components, and operates reliably from -40°C to +85°C, making it ideal for industrial and power management applications.
TRACO POWER TEN34821WIN Dual Output DC-DC Converter Specifications:
- Input voltage range: 18VDC to 75VDC
- Input current no load: 20 mA typ.
- Start-up voltage: 18 VDC or lower
- Surge voltage (1 s): 100 V max.
- Input/Output isolation voltage: 1500 VDC
- Output voltage: ±5 VDC
- Output current: 250 mA max.
- Efficiency: 80%
- Operating temperature: -40°C to +85°C
- Isolation resistance: >1,000 MΩ at 500 VDC
- Isolation capacitance: 300 pF max.
- Ripple and noise: 70 mVpk-pk
- MTBF: >1 million hours
- Safety standards: UL 60950-1, IEC/EN 60950-1
- Dimensions: 20.3 mm x 10.2 mm x 31.8 mm
- Switching frequency: 90 kHz min.
- Enclosure: FR4 non-conductive with UL 94V-0 epoxy potting
- Pin material: Gold-plated copper alloy
- Protection: Continuous short circuit, automatic recovery
Buy the Buy TracoPower TEN 3-4821WIN Part Number TEN34821WIN Online
Purchase the TracoPower TEN 3-4821WIN today for dependable dual output power with wide input range, high efficiency, and proven reliability. Engineered for industrial applications, it offers automatic short circuit protection, EMC compliance without external components, and an extended temperature range to ensure optimal performance in demanding environments. Its compact size, UL approval, and robust construction make it the ideal choice for power management and automation systems. Order now to secure fast delivery and get a high-quality, cost-effective power solution for your projects.
Order your TracoPower SeriesTEN 3-4821WIN today and give your industrial projects reliable power with high efficiency and safety standards.
Frequently Asked Questions
Where can I buy TRACO POWER TEN34821WIN?
You can click on the BUY or RFQ button to purchase TEN34821WIN from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEN34821WIN?
You can download the TEN34821WIN datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEN34821WIN?
TRACO POWER
