TRACO POWER THL101223 Industrial DC/DC Converter
The THL 10 series from TracoPower consists of 10W single and dual output DC/DC converters designed for general purpose industrial and communication applications. These compact converters are housed in a 1" x 1" metal case with a shielded design and isolated baseplate, offering a reliable and durable solution. They feature an industrial standard pinout, a wide 2:1 input voltage range, and an input filter compliant with EN 55022 Class A, eliminating the need for external components. The converters provide short circuit, overvoltage protections, and operate effectively within a temperature range of -40°C to +80°C, up to +85°C with a heatsink. The models are certified to UL/cUL 60950-1 and IEC/EN 60950-1 safety standards, with a 3-year warranty. Key features include high efficiency up to 89%, 1500VDC I/O isolation voltage, low ripple and noise, and a fixed PWM switching frequency of approximately 300kHz. Suitable for instrumentation, distributed power architectures, and industrial electronics.
TRACO POWER THL101223 Industrial DC/DC Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: Wide 2:1 range (e.g., 9-36 VDC, 18-75 VDC, 36-75 VDC models)
- Output Voltage Options: 3.3 VDC, 5.1 VDC, 12 VDC, 15 VDC, +5.0 VDC, +12 VDC, +15 VDC
- Output Current Max.: 2500 mA for 3.3 V models, 2000 mA for 5.1 V models, 830 mA for 12 V models, 670 mA for 15 V models
- Efficiency: Up to 89%
- Isolation Voltage: 1500 VDC input/output
- Operating Temperature Range: -40°C to +80°C, up to +85°C with heatsink
- Switching Frequency: 300 kHz typ.
- Mechanical Case: Metal
- Dimensions: 1" x 1" x 0.4" (25.4 mm x 25.4 mm x 10 mm)
- Protection: Short circuit, overvoltage, automatic hiccup recovery
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1
- Soldering Temp.: Max +260°C for 10 seconds
- Input Current at Full Load: 12 V models approx. 800 mA
- Input Current at No Load: 12 V models approx. 15 mA
- Surge Voltage: 25 V for 12 V models, 50 V for 24 V models, 100 V for 48 V models
- Humidity: Up to 95% RH non-condensing
- Reliability: MTBF approx. 2,596,000 hours
Buy the TracoPower THL 10 Series – Reliable DC-DC Converters for Industrial Applications
Secure your power management needs with the TracoPower THL 10 series DC/DC converters. These reliable 10W power modules feature high efficiency up to 89%, wide input ranges, and comprehensive protection. Perfect for industrial electronics, instrumentation, and distributed power systems, they operate efficiently from -40°C to +80°C, with optional heatsinks for higher temperatures. Certified for safety standards UL/cUL 60950-1 and IEC/EN 60950-1, these durable converters provide stable output voltages and low ripple, ensuring a consistent power supply for demanding environments. Order online now and enhance your projects with trusted power solutions.
Order your TracoPower series THL 10 DC/DC converter today and ensure dependable power supply in your industrial and communication projects.
