TRACO POWER TPP15148AD Medical Power Supply
This component is designed for medical applications, ensuring high reliability and performance in critical healthcare equipment. It features high efficiency up to 89%, low leakage current below 75 pA, and is IEC/EN/ES 60601-1 3rd edition compliant for 2 x MOPP. The compact open frame power supply operates at 85-264 VAC with a full load temperature range of -40°C to +60°C, derated to 85°C at 50% load. It offers excellent EMC performance, is capable of operating at altitudes up to 5000 m, and includes a 5-year warranty, making it ideal for sensitive medical devices.
TRACO POWER TPP15148AD Medical Power Supply Specifications:
- Output Power: 15 W
- Output Voltage: 15 VDC (135 - 165 VDC)
- Output Current: 1000 mA
- Efficiency: 87%
- Input Voltage: 85 - 264 VAC / 120 - 370 VDC
- Input Frequency: 47 - 63 Hz
- No Load Power Consumption: 75 mW max
- Operating Temperature Range: -40°C to +60°C (full load), up to 85°C with derating
- Altitude Compatibility: Up to 5000 m
- Leakage Current: <75 pA
- Isolation Voltage: 5,000 VAC input to output
- Protection Class: II reinforced insulation
- Standards: IEC 60601-1, IEC 62368-1, UL 62368-1
- EMC Immunity & Emission: Meets IEC 60601-1-2 4th edition
- Physical Dimensions: 1.0 x 1.5 inches (25.4 x 38.1 mm)
- Cooling: Natural convection
- Warranty: 5 years
- Certifications: IEC/EN/ES 60601-1 3rd edition, 2x MOPP
Buy the Traco Power TPP15148AD – Reliable Medical Power Supply for Healthcare Equipment
Experience the superior quality and dependability of the Traco Power TPP15148AD, a 15-watt medical power supply designed for critical healthcare applications. With high efficiency of up to 89%, ultra-low leakage current, and full compliance with IEC 60601-1 and IEC 62368-1 standards, this open frame power supply ensures safety and reliability. Its compact size, operating at 85-264 VAC, makes it ideal for space-constrained medical devices. Enjoy peace of mind with a 5-year warranty and worldwide approval for altitude and performance.
Get Traco Power TPP15148AD today—built for medical-grade reliability in healthcare devices.
Frequently Asked Questions
Where can I buy TRACO POWER TPP15148AD?
You can click on the BUY or RFQ button to purchase TPP15148AD from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP15148AD?
You can download the TPP15148AD datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP15148AD?
TRACO POWER
