TRACO POWER TEN402415WIE DC/DC Converter
The TEN 40WIE is a high-efficiency, 40-watt DC/DC converter featuring a compact 2”x1” metal package with a 4:1 input voltage range of 9-36V or 18-75V. It offers excellent temperature performance from -40°C to +85°C, with efficiencies up to 93%, suitable for industrial applications. The series includes multiple models with different output voltages, remote On/Off control, and protection features against short circuits, overvoltage, and over temperature. Certified for IEC/EN/UL 62368-1, it combines reliability, safety, and high performance for demanding environments.
TRACO POWER TEN402415WIE DC/DC Converter Specifications:
- Input Voltage Range: 9-36 VDC or 18-75 VDC with 4:1 ratio
- Maximum Input Surge Voltage: 50 VDC (24 V models), 100 VDC (48 V models)
- Output Power: 40 Watts
- Output Voltage Adjustment: ±10% (15 & 24 V models), ±10% (other models)
- Voltage Set Accuracy: ±1%
- Efficiency: Up to 93%
- Operating Temperature Range: -40°C to +85°C
- Isolation Voltage: 1600 VDC input/output
- Startup Time: 30 ms typical
- Short Circuit Protection: Automatic recovery
- Protection: Overvoltage, overtemperature, short circuit
- Insulation Resistance: ≥1000 MΩ at 500 VDC
- Switching Frequency: 225-275 kHz (WIE series)
- Cooling: Natural convection
- Housing Material: Copper
- Weight: 34g
- Certifications: IEC 62368-1, UL 62368-1, EN 62368-1
- Environmental Compliance: RoHS, Reach
- Size: 2″ x 1″ x 0.5″
Buy the Traco Power Series TEN 40WIE DC/DC Converter: TEN402415WIE
Secure your Traco Power Series TEN 40WIE DC/DC Converter online today and benefit from its high efficiency, robust protection features, and certification compliance. Designed for demanding industrial environments, it offers precise voltage regulation, universal input voltage range, and safety protections including short circuit, overvoltage, and over temperature. Perfect for powering various industrial systems with compact size and reliable performance. Make your purchase now and ensure your projects operate flawlessly with trusted power conversion solutions from a leading brand, backed by a three-year warranty.
Order your Traco Power Series TEN 40WIE DC/DC Converter today and give your industrial projects the reliable power efficiency they deserve.
