TRACO POWER TEN152412WI DC/DC Converter
The TEN 15WI series of 15-watt DC/DC converters is designed for reliable power applications in industrial systems, communications, and battery-powered devices. Featuring ultra-wide input ranges, high efficiency up to 86%, and an extended operating temperature from -40°C to +85°C, these converters provide robust performance. They include built-in filters meeting EN 55022, FCC Level A standards, and possess short circuit protection, remote On/Off, and industry-standard pinouts in a six-sided shielded case. Fully RoHS compliant with a 3-year warranty, they ensure dependable and durable power conversion.
TRACO POWER TEN152412WI DC/DC Converter Specifications:
- Input voltage range: 3.3 VDC to 36 VDC, 18-75 VDC for some models
- Output voltages: 3.3 VDC, 5.1 VDC, 9-36 VDC, 12 VDC, 15 VDC, 18-75 VDC, 24 VDC, 48 VDC
- Maximum output current: up to 1250 mA
- Efficiency: up to 86%
- Operating temperature: -40°C to +85°C
- Isolation voltage: 1500 VDC
- Ripple and noise: 80 mVpk-pk
- Switching frequency: 330 kHz
- Case material: Copper, nickel plated
- Dimensions: Support pin pitch 2.54 mm, length approximately 35 mm
- Protection: Indefinite short circuit, automatic recovery
- Certifications: UL 60950-1, IEC/EN 60950-1, RoHS compliant
- Humidity: 95% rel H max.
- MTBF: >700,000 hours
Buy the Buy TracoPower DC/DC Converter Part Number TEN152412WI Online
Purchase the TracoPower TEN 15WI 15-watt DC/DC converter online today for your industrial systems, communications, or battery-powered equipment. Featuring a wide input range, high efficiency up to 86%, and extended temperature operation from -40°C to +85°C, this converter is built for durability and reliability. Its built-in EN 55022, FCC Level A filters, automatic short circuit protection, and industry-standard pinout make installation simple and maintenance minimal. Fully RoHS compliant, it offers a robust power solution with a 3-year warranty for all demanding applications.
Order your TracoPower SeriesTEN152412WI 15 Watt DC/DC Converter today and ensure reliable power supply for your industrial and communication projects.
