TRACO POWER TENHS6 DC/DC Converter
The TEN 50WI Series is a set of high-performance isolated DC/DC converter modules delivering 50 W power in a compact 1" x 2" x 0.4" form factor with up to 92% efficiency. Featuring a wide 4:1 input range, adjustable output voltage, remote On/Off, and protection against over-temperature, these converters operate from -40°C to +80°C, with optional heatsink for higher temperature endurance. Ideal for mobile devices, instrumentation, and distributed power systems in communications and industrial electronics, they ensure high reliability and space-saving installation.
TRACO POWER TENHS6 DC/DC Converter Specifications:
- Input Voltage Range: 18-75 VDC
- Output Voltage Options: 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, 24 VDC with high current outputs
- Efficiency: Up to 92%
- Operating Temperature: -40°C to +80°C, with derating
- Isolation Voltage: 1500 VDC
- Ripple and Noise: 100-150 mVpk-pk depending on model
- Dimensions: 1" x 2" x 0.4" (25.4 x 50.8 x 10.16 mm)
- Weight: 34 g
- Protection: Over-temperature, overload, short circuit with hiccup mode
- Switching Frequency: 285 kHz
- Thermal Impedance: 12°C/W (natural convection), optional heatsink reduces to 10°C/W
- MTBF: >230,900 hours at +25°C
- Certifications: UL, CSA, IEC 60950-1 safety standards
Buy the Buy TracoPower DC/DC Converter Part Number TENHS6 Online
Discover the TracoPower TENHS6, a reliable 50W DC/DC converter designed for space-constrained industrial, communication, and instrumentation systems. Offering high efficiency up to 92%, wide input voltage range, adjustable output, and protection features, it ensures stable power delivery under harsh conditions. Its compact size saves space on your PCB, making it ideal for mobile equipment and distributed power architectures. Easy to install with optional heatsink, the TENHS6 guarantees long-lasting performance with safety standards compliance. Purchase online today for professional-grade power conversion.
Get TracoPower TENHS6 today—compact high-efficiency power supply for industrial and communication applications.
Frequently Asked Questions
Where can I buy TRACO POWER TENHS6?
You can click on the BUY or RFQ button to purchase TENHS6 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TENHS6?
You can download the TENHS6 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TENHS6?
TRACO POWER
