TRACO POWER THD104822N DC/DC Converter
The THD 10 Series from TracoPower features 10W isolated DC/DC converters in a compact DIP-24 package, ideal for industrial, instrumentation, and communication applications. They support wide 2:1 input voltage ranges (12V, 24V, 48V), deliver up to 3A output current, and achieve efficiencies up to 88%. Equipped with an internal EMI filter, overvoltage, overload, and short circuit protections, these converters ensure reliable operation across -40°C to +85°C. Their low ripple, noise, and 1500VDC I/O isolation make them suitable for space-constrained, high-performance electronic systems with certified safety compliance.
TRACO POWER THD104822N DC/DC Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: 12VDC, 24VDC, 48VDC with a 2:1 ratio
- Output Voltages: 3.3VDC, 5.1VDC, 12VDC, ±12VDC, ±15VDC, max 3A
- Efficiency: Up to 88%
- Isolation Voltage: 1500 VDC for 60 seconds
- Ripple and Noise: Max 85mVp-p
- Operating Temperature Range: -40°C to +85°C
- Switching Frequency: Approximately 330-400 kHz
- Protection: Overvoltage, overload, short circuit with hiccup mode
- Physical Dimensions: 20.3mm x 10.2mm x 31.8mm
- Input Current at No Load: 12V models ~20mA, 24V models ~15mA, 48V models ~10mA
- Certifications: UL/cUL 60950-1, EN 60950-1, RoHS compliant
- Safety & EMC Standards: EN 55022 Class A, EN 55024, EN 61000-4 series
- Pin configuration includes Remote On/Off and Vout options
- Weight: Approx 173g
- Material: Metal casing with non-conductive base, copper pins
Buy the Traco Power Series THD 10N DC/DC Converter: THD4822N
Discover the reliable performance of the Traco Power Series THD 10N DC/DC Converter, offering 10W power output, wide input voltage range, high efficiency up to 88%, and comprehensive protections. Designed with a compact DIP-24 package, it features built-in EMI filtering, optional remote on/off, and a maximum isolation voltage of 1500VDC suitable for industrial, instrumentation, and communication systems. Certified according to UL and EN standards, it operates from -40°C to +85°C. Purchase now online to ensure your projects are powered with this dependable, top-quality converter with a 3-year warranty.
Order your Traco Power Series THD 10N DC/DC Converter today and ensure reliable, high-efficiency power for space-constrained industrial and automation projects.
Frequently Asked Questions
Where can I buy TRACO POWER THD104822N?
You can click on the BUY or RFQ button to purchase THD104822N from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THD104822N?
You can download the THD104822N datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THD104822N?
TRACO POWER
