TRACO POWER THM202415 Medical Power Converter
The THM-20 series comprises medical-grade 20-watt DC/DC converters housed in a compact 1.6x1 inch plastic case, designed for medical and industrial applications. These converters provide reinforced 5000 VACrms isolation, ultra-low leakage current below 2.5 pA, and operate within an extended temperature range from -40°C to +80°C. Certified to IEC/EN/ES 60601-1 3rd edition for 2 x MOPP, they offer high efficiency up to 90%, excellent noise suppression, and can operate at altitudes up to 5000 meters. Ideal for medical, transportation, control, measurement, and IGBT driver systems.
TRACO POWER THM202415 Medical Power Converter Specifications:
- Input voltage range: 5.0 VDC to 42 VDC, 9 VDC to 48 VDC, up to 60 V maximum surge voltage
- Output voltage options: 5 V, 9 V, 12 V, 15 V, 24 V, with current ratings from 667 mA to 4000 mA
- Efficiency: Up to 90% with models like THM 20-2414, THM 20-2412, THM 20-2413, THM 20-2415
- Isolation voltage: 5000 VACrms, reinforced, with creep distance of at least 8 mm
- Operating temperature: -40°C to +80°C, derating at 2%/K above 55°C, max temperature 105°C
- Protection: Overcurrent (150-185%), short circuit, overvoltage (6.2V to 30V), and overtemperature at 115°C
- Ripple and noise: 50–100 mVp-p, transient response within 250 µs, regulation within 0.2-1.0%
- Dimensions: 25.4x25.4x13 mm (1.00x1.00x0.51 inches), weight approx. 249 g
- EMC: Conducted and radiated noise compliant with IEC 60601-1-2, EN55032, EN61000 series
- Mechanical: Non-conductive silicone potting, UL94 V-0 rated plastic casing, soldering max temp. 265°C/10s
- Altitude: Up to 5000 m, humidity: 5-95% non-condensing, safety standards IEC/EN/ES 60601-1, ISO 13485 certified
Buy the Traco Power THM202415 – Reliable Medical Power Supply for Industrial Applications
Purchase the Traco Power THM202415 now for your medical and industrial projects. Offering 20 watts of power, reinforced 5000 VACrms isolation, ultra-low leakage current, and high efficiency up to 90%. Designed for operation from -40°C to +80°C, it ensures reliable performance in demanding environments. With certifications according to IEC/EN/ES 60601-1 and compliance with EMC standards, this compact and durable power converter is ideal for medical equipment, transportation, control systems, and measurement applications. Buy online today for quick delivery.
Get Traco Power THM202415 today—built for medical and industrial precision with high efficiency and reinforced isolation.
Frequently Asked Questions
Where can I buy TRACO POWER THM202415?
You can click on the BUY or RFQ button to purchase THM202415 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THM202415?
You can download the THM202415 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THM202415?
TRACO POWER
