TRACO POWER TCK059 Power Inductor
The TCK-059 inductor offers a high-current, reliable solution for electronic circuits with an inductance of 2.2 microhenries, rated up to 4.8 A. Designed to operate within a temperature range of -40°C to +125°C, it features a low DCR of 25 milliohms for efficiency. Its compact outline dimensions and PCB pattern make it suitable for sophisticated power management applications in demanding environments. A perfect choice for engineers seeking high-performance inductors with stable impedance characteristics across various operating conditions.
TRACO POWER TCK059 Power Inductor Specifications:
- Inductance: 2.2 µH +20% (at 1 kHz / 250 mV)
- Impedance (DCR): 25 mOhm max
- Rated Current: 4.8 A max
- Operating Temperature: -40°C to +125°C
- Outline Dimensions: A 5.2 +0.5 mm, B 5.8 +0.5 mm, C 4.5 +0.55 mm, D 2.3 mm (typ), E 5.5 mm, F 2.15 mm, G 1.7 mm
- PCB Pattern: Detailed pattern specifications included
- Impedance Curve: Available for performance analysis
- Manufacturer: Traco Power
- Model: TCK-059
Buy the Traco Power TCK-059 – Reliable Inductor for Industrial Applications
Order the Power Inductor now to enhance your electronic circuits with high current capacity and exceptional efficiency. Designed for industrial and demanding applications, it ensures reliable performance across a wide temperature range from -40°C to +125°C. Featuring a compact outline and low DCR of 25 milliohms, this inductor supports up to 4.8 A, making it ideal for power supplies and motor drives. Purchase online easily and ensure your projects are equipped with high-quality, durable inductors from a trusted manufacturer.
Get Traco Power TCK-059 today—built for precision and long-lasting durability in power management systems.
Frequently Asked Questions
Where can I buy TRACO POWER TCK059?
You can click on the BUY or RFQ button to purchase TCK059 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TCK059?
You can download the TCK059 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TCK059?
TRACO POWER
