TRACO POWER TPC055124 Industrial Power Supply
The TPC series offers compact, high-efficiency industrial power supplies suitable for various environments, including industrial, office, and residential settings. These switches feature universal input (85-264 VAC), adjustable output voltage, low no-load power consumption under 0.3W, and multiple safety and certifications such as UL, CB, and CSA. Designed for DIN-rail or wall mounting, they include protections like overload, short-circuit, and overvoltage. The series provides models from 30 to 120W with outputs of 5V, 12V, 24V, and 48V, ensuring reliable performance across demanding applications.
TRACO POWER TPC055124 Industrial Power Supply Specifications:
- Input Voltage: 85-264 VAC, 47-63 Hz / 90-375 VDC
- Output Power: 30W, 55W, 80W, 120W models
- Output Voltage: 5 VDC / 5.0-6.0 VDC, 12 VDC / 12-15 VDC, 24 VDC / 24-28.8 VDC, 48 VDC / 48-56 VDC
- Output Current: up to 25A depending on model
- Dimensions: Vary by model, approximately 26.5-72 mm W, 90 mm H, 96.5-110 mm D
- Efficiency: 79% to 87% depending on model
- Operating Temperature: -25°C to +70°C, derating above 50°C
- Mounting: DIN-rail and wall mounting options
- Safety Certifications: UL, CB, CSA, IEC 60950-1
- Protection: Overload, short-circuit, and overvoltage protections
- Standby Power Consumption: <0.3W to <0.5W
- Isolation Voltage: 3000 VAC input/output
Buy the Traco Power Series TPC Power Supply: 55W 55-056VDC
Order the Traco Power Series TPC 055124 online for a high-efficiency, versatile power supply tailored for industrial, office, and residential environments. With adjustable output voltage from 24 to 28.8V, low standby power consumption under 0.3W, multiple safety certifications, and comprehensive protections, this 55W model provides reliable, long-lasting performance. Its compact design supports DIN-rail and wall mounting, ensuring easy installation in various setups. Whether for automation, control systems, or industrial applications, buy now for quality and dependability.
Get Traco Power Series TPC 055124 today—built for efficiency, reliability, and versatile industrial applications.
