TRACO POWER THN202412WI DC/DC Converter
The THN 20WI series offers high-performance 20-watt DC/DC converters in a compact 1.0” x 1.0” x 0.4” shielded metal case with isolated baseplate. These converters feature an ultra-wide input voltage range of 4:1, up to 90% efficiency, and adjustable output voltages. They operate in temperatures from -40°C to +75°C (up to +85°C with heat-sink), with low no-load input current, remote On/Off control, and 1500 VDC isolation. Ideal for space-constrained industrial, communication, and mobile applications, they are RoHS compliant with a 3-year warranty.
TRACO POWER THN202412WI DC/DC Converter Specifications:
- Input voltage range: 3.3 VDC to 48 VDC with surge protection up to 50V or 100V
- Output voltages: 3.3 V, 5 V, 12 V, 15 V, 24 V, adjustable models up to 6 V
- Output current: up to 4.5 A, depending on model
- Efficiency: up to 90%
- Operating temperature: -40°C to +75°C (up to +85°C with heat-sink)
- Isolation voltage: 1500 VDC
- Ripple and noise: 75 mVp-p typical with external capacitor
- Power derating: 2.0 %/K above 60°C without heat sink, 70°C with heat sink
- Switching frequency: 330 kHz
- Dimensions: 1.0” x 1.0” x 0.4” (25.4 x 25.4 x 10 mm)
- Weight: approximately 15 g
- Protection: short circuit, overvoltage, remote On/Off control
- Certifications: UL, cUL, IEC 60950-1, RoHS compliant
Buy the Buy Traco Power DC/DC Converter Part Number THN202412WI Online
Purchase the Traco Power THN 20WI series DC/DC converters online for versatile, high-efficiency power solutions suitable for industrial electronics, communication systems, and mobile equipment. These compact converters deliver up to 20 watts with adjustable voltage outputs, wide input ranges, and excellent thermal performance. They feature remote On/Off control, low no-load input current, and isolation voltage of 1500 VDC, ensuring safe and reliable operation across temperature ranges up to 85°C. Ideal for PCB space-constrained applications requiring durable and efficient power conversion.
Get Traco Power THN202412WI today—designed for high efficiency and reliable power delivery in compact form factors.
Frequently Asked Questions
Where can I buy TRACO POWER THN202412WI?
You can click on the BUY or RFQ button to purchase THN202412WI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN202412WI?
You can download the THN202412WI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN202412WI?
TRACO POWER
