TRACO POWER THN302423 DC/DC Converter
The THN 30 Series is a high-performance 30W DC/DC converter module designed for space-constrained applications, offering high efficiency up to 92% and wide input voltage ranges of 2:1 ratio. Encased in a compact, shielded metal case measuring just 1.0” x 1.0” x 0.4”, it features excellent thermal management, over temperature protection, and remote On/Off control. Suitable for industrial, communication, and battery-powered systems, these converters deliver reliable, regulated outputs with low no-load input current, making them ideal for distributed power architectures.
TRACO POWER THN302423 DC/DC Converter Specifications:
- Input Voltage Range: 2:1 wide range, models available from 9 VDC to 75 VDC
- Output Power: 30 Watts
- Efficiency: Up to 92%
- Operating Temperature: -40°C to +80°C, up to 85°C with heatsink
- Dimensions: 1.0” x 1.0” x 0.4” (25.4mm x 25.4mm x 10.16mm)
- Isolation Voltage: 1500 VDC input to output, 1000 VDC input/output to case
- Output Voltage Adjustment Range: ±10% to +20% depending on model
- Ripple & Noise: 75 mVp-p typical, measured with specified output capacitors
- Protection: Over temperature, short circuit, over voltage
- Input Current at No Load: 12V models 12 mA, 24V models 10 mA, 48V models 8 mA
- Switching Frequency: 275 kHz to 330 kHz depending on model
- Isolation Capacitance: Maximum 1500 pF
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, RoHS 2011/65/EU
- Material: Copper casing, UL 94V-0 rated potting
- Weight: Approx. 16.5 g
Buy the Traco Power Series THN DC/DC Converter: THN 30-1210
Order the Traco Power THN 30-1210 DC/DC converter online today and benefit from high efficiency up to 92%, wide input voltage range, and reliable output regulation. Its ultra-compact size makes it perfect for space-constrained systems in industrial electronics, communication equipment, and battery-powered applications. With features like remote On/Off control, over temperature protection, and excellent thermal management, this converter ensures dependable operation in harsh environments. Simple ordering process guarantees quick delivery, enabling your projects to stay on schedule with proven, high-quality power solutions.
Buy Traco Power THN 30-1210 now and experience unmatched reliability and high efficiency in a compact design for demanding industrial applications.
Frequently Asked Questions
Where can I buy TRACO POWER THN302423?
You can click on the BUY or RFQ button to purchase THN302423 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THN302423?
You can download the THN302423 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THN302423?
TRACO POWER
