TRACO POWER TPP15105AD Medical Power Supply
The TPP 15A-D Series is a highly efficient 15-watt power supply designed for medical equipment, featuring low leakage current and compliance with IEC 60601-1 standards for patient safety. It offers an operating temperature range from -40°C to +60°C, with derating up to 85°C at 50% load. The unit provides various output voltages, including 3.3V, 5V, 9V, 12V, 15V, 24V, 36V, and 48V, with efficiencies up to 89%. It includes reinforced insulation, class II protection, and is suitable for high-altitude operation up to 5000 meters, making it ideal for medical and industrial applications.
TRACO POWER TPP15105AD Medical Power Supply Specifications:
- Output Power: 13.2W to 15W depending on model
- Input Voltage Range: 85-264 VAC / 120-370 VDC (no certification)
- Output Voltage: 3.3V to 48V with adjustable regulation 10%
- Efficiency: Up to 89%
- Operating Temperature: -40°C to +60°C; derates to 85°C at 50% load
- Protection Class: II, Reinforced Insulation
- Leakage Current: <75 μA
- Operating Altitude: Up to 5000 m
- Frequency Range: 47-63 Hz
- Power Consumption at No Load: 75 mW max.
- Isolation Test Voltage: 5,000 VDC input to output, 2,121 VDC input to case/PE
- Ripple & Noise: 40-140 mVp-p depending on model
- Dimensions: Approx. 1.0” x 1.5” in packaging format
- Standards: IEC 60601-1, IEC 62368-1, UL 62368-1, EN 60601-1, and others
- Environmental: Supports operation at 5000 m altitude, 95% humidity (non-condensing)
- Certifications: IEC/EN/ES 60601-1, UL 62368-1, CE, RoHS, Reach
- Reliability: MTBF approximately 300,000 hours
Buy the Traco Power TPP 15A-D – Reliable Medical Power Supply for Industrial Applications
Purchase the Traco Power TPP 15A-D Series online today to secure a certified, high-performance power supply ideal for medical and industrial applications. With low leakage current, reinforced insulation, and efficiencies up to 89%, this power supply ensures safety and reliability in demanding environments. Its compact open-frame design fits easily into various devices, supporting operation at high altitudes up to 5000 meters and wide temperature ranges from -40°C to +60°C. Enjoy fast online ordering and guaranteed quality for your essential equipment needs.
Buy Traco Power TPP 15A-D now and experience unmatched reliability and high efficiency in your medical and industrial devices.
Frequently Asked Questions
Where can I buy TRACO POWER TPP15105AD?
You can click on the BUY or RFQ button to purchase TPP15105AD from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP15105AD?
You can download the TPP15105AD datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP15105AD?
TRACO POWER
