TRACO POWER TMV22415SHI DC-DC Converter
The TMV 2HI series by Traco Power offers compact, non-regulated 2-watt DC/DC converters designed for high input/output isolation of 5,200 VDC, suitable for IGBT applications. Features include an ultra-compact SIP-7 package, operating temperature range from -40°C to +85°C, and industry-standard pinout. These converters provide stable voltage regulation with maximum efficiencies up to 85% across various models, ensuring reliable performance in demanding industrial environments. Ideal for power supply, automation, and control systems where high voltage isolation and robustness are critical.
TRACO POWER TMV22415SHI DC-DC Converter Specifications:
- Input Voltage: 3.3 VDC to 24 VDC, surge max. 9 V to 30 V
- Output Voltage: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V
- Output Current: 66 mA to 500 mA depending on model
- Efficiency: Up to 85%
- Isolation Voltage: 5,700 Vpk (5200 VDC test)
- Ripple and Noise: 100 mVp-p max.
- Operating Temperature Range: -40°C to +85°C
- Case Material: Non-conducting FR4
- Pin Material: Tinned copper
- Dimensions: 19.5 mm x 14 mm x 9.5 mm, package weight approximately 2.49 g
- Certifications: UL, CSA, IEC 60950-1, RoHS compliant
- Switching Frequency: ~100 kHz
- Soldering Temperature: Max. 260°C for 10 s
- Short Circuit Protection: Continuous, automatic recovery
- Isolation Capacitance: 7 pF, Resistance: >10 GΩ
Buy the Traco Power Series TMV2HI DC-DC Converter: TMV22415SHI
Order the Traco Power TMV22415SHI DC-DC converter online today and enjoy a highly reliable, efficient power solution with high isolation voltage of 5200 VDC, suitable for demanding industrial environments. This compact, SIP-7 package offers adjustable output voltages including 15 V, 12 V, 9 V, and 5 V, with efficiencies reaching up to 85%. Its wide operating temperature range from -40°C to +85°C, combined with robust safety standards and certifications, makes it ideal for power supply applications requiring high performance and safety in automation and control systems.
Buy Traco Power TMV22415SHI now and experience unmatched reliability and high-voltage isolation in compact industrial power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TMV22415SHI?
You can click on the BUY or RFQ button to purchase TMV22415SHI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMV22415SHI?
You can download the TMV22415SHI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMV22415SHI?
TRACO POWER
