TRACO POWER TME0512S DC/DC Converter
The TME series consists of ultra-compact, isolated DC/DC converters in a SIP package requiring minimal 0.7 cm² board space. Designed for efficiency, these 1-watt power modules serve to generate isolated voltages in various applications with industry-standard pinouts and full testing for reliability. They operate from -40°C to +85°C, feature up to 80% efficiency, and include protections such as short circuit limits and reverse polarity. Suitable for space-constrained electronic and industrial systems, these converters offer a cost-effective, high-reliability power solution worldwide.
TRACO POWER TME0512S DC/DC Converter Specifications:
- Input Voltage: 3.3 VDC, 5 VDC, 12 VDC, 24 VDC options
- Output Voltage: 3.3 VDC, 5 VDC, 9 VDC, 12 VDC, 15 VDC, 24 VDC
- Output Current Max: 260 mA, 200 mA, 110 mA, 84 mA, 67 mA
- Efficiency: Up to 80%
- Operating Temperature Range: -40°C to +85°C
- Isolation Voltage: 1000 VDC input/output
- Ripple and Noise (20 MHz): 150 mVp-p max
- Switching Frequency: 50-110 kHz
- Protection: Short circuit limited to 0.5 s, reverse polarity input current 0.3 A max
- Humidity: Up to 95% RH non-condensing
- Dimensions: Small SIP package, weight 1.3 - 1.7 g
- Case Material: UL 94V-0 rated black plastic
- Soldering Temperature: Max 265°C / 10 s
- Isolation Capacity: 60 pF typical
- Isolation Resistance: >1,000 MΩ
Buy the Buy TRACO POWER TME Series 1 Watt Part Number TME0512S Online
Purchase the high-efficiency, space-saving DC/DC converter from TRACO POWER's TME series online today. With a 1-watt power rating and operating temperature range of -40°C to +85°C, this compact SIP-packaged module delivers reliable power in space-constrained industrial and electronic applications. Featuring up to 80% efficiency, industry-standard pinout, and proven durability with 100% burn-in testing, it guarantees high reliability and performance. Ensure seamless integration and superior power isolation for your project by ordering online now.
Order your TRACO POWER TME Series TME0512S today and ensure reliable, space-efficient power conversion for your electronic projects.
Frequently Asked Questions
Where can I buy TRACO POWER TME0512S?
You can click on the BUY or RFQ button to purchase TME0512S from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TME0512S?
You can download the TME0512S datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TME0512S?
TRACO POWER
