TRACO POWER TMV22415DHI industrial DC/DC converter
The TMV 2HI Series is a compact 2 Watt DC/DC converter with high I/O isolation of 5200 VDC, ideal for IGBT applications and industrial environments. It features a SIP-7 package, operates efficiently from -40°C to +85°C, and includes multiple models with various output voltages like 3.3V, 5V, 9V, 12V, and 15V. The device provides low ripple and noise, automatic short circuit protection, and excellent durability suitable for high-reliability industrial applications.
TRACO POWER TMV22415DHI industrial DC/DC converter Specifications:
- Input voltage: 3.3V to 24V DC with surge voltage up to 30V max.
- Output Voltage: 3.3V, 5V, 9V, 12V, 15V ±5% accuracy.
- Output Current: 66mA to 500mA depending on model.
- Efficiency: 74% to 85%, depending on model.
- Isolation Voltage: 5200VDC tested.
- Operating Temperature: -40°C to +85°C.
- Ripple and Noise: max. 100mVp-p.
- Short Circuit Protection: automatic recovery.
- Dimensions: SIP-7 package, approximately 19.5mm x 18.5mm.
- Soldering temperature: max. 260°C / 10s.
- Case Material: Non-conducting FR4.
- Pin Material: Tinned Copper.
Buy the Buy Traco Power DC/DC Converter Series TMV 2HI Part Number TMV22415DHI Online
Purchase the Traco Power TMV 2HI series DC/DC converter online today to ensure a durable, high-performance power solution for industrial applications. With high I/O isolation of 5200V, compact SIP-7 design, and temperature tolerance from -40°C to +85°C, this converter offers reliable voltage regulation across multiple models. Perfect for industrial systems, automation, and IGBT power supplies, this converter also provides low ripple noise, automatic short circuit protection, and excellent efficiency, ensuring long-lasting performance in demanding environments.
Get Traco Power TMV22415DHI today—built for high efficiency and reliable industrial power conversion.
Frequently Asked Questions
Where can I buy TRACO POWER TMV22415DHI?
You can click on the BUY or RFQ button to purchase TMV22415DHI from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMV22415DHI?
You can download the TMV22415DHI datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMV22415DHI?
TRACO POWER
