TRACO POWER TMPS10115 Industrial Power Module
The TMPS 10 series offers ultra-compact 10 Watt AC/DC power modules suitable for PCB mounting in household and industrial appliances. Certified to IEC/EN/UL 62368-1 and IEC/EN 60335-1, these modules feature reinforced I/O isolation up to 4000 VAC, operate within -25°C to +70°C, and support peak currents of 130% for 30 seconds. They meet ErP directives with low no-load power consumption (<0.15W), EMI standards EN 55032 class B and EN 55014-1, and come with a 3-year warranty, making them ideal for space-constrained low-power applications.
TRACO POWER TMPS10115 Industrial Power Module Specifications:
- Input voltage: AC 85 — 264 VAC, DC 120 - 370 VDC
- Input frequency: 47 — 63 Hz (designed for 47 — 440 Hz)
- Leakage current: 0.25 mA max.
- Inrush current: 20A at 115 VAC, 40A at 230 VAC
- No-load power: <0.15 W
- Output voltages: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V, 48 V
- Output current: up to 2600 mA (depending on model)
- Efficiency: 77% to 86%
- Voltage accuracy: ±1% typical
- Line regulation: 0.5% max.
- Load regulation: 1.0% max.
- Hold-up time: 8 ms at 115 VAC, 40 ms at 230 VAC
- Ripple and noise: 60 mVp-p (20 V bandwidth)
- Overvoltage protection: 125% of Vout
- Short circuit protection: hiccup, auto recovery
- Isolation voltage: 4000 VAC (input/output)
- Operating temperature: -25°C to +70°C, derating 2.5%/K above 50°C
- MTBF: 450,000 hours at 25°C
- Case: Plastic resin (UL 94V-0 rated)
- Pin material: Tinned copper
- Dimensions: 1
- 1.5
Buy the Buy Traco Power TMPS 10 Series Part Number TMPS10115 Online
Purchase the Traco Power TMPS 10 series power modules online to ensure your low-power circuits are reliable, efficient, and compliant with safety and environmental standards. These compact units deliver 10 Watts with adjustable output voltages, reinforced isolation, and excellent efficiency. Ideal for space-constrained applications, they feature low no-load power consumption, robust EMI compliance, and universal input ranges, making them the perfect choice for modern household, industrial, and IT devices needing secure and stable power supply.
Get Traco Power TMPS 10 series 10 Watt power module today—built for space-efficient, reliable industrial and household power solutions.
Frequently Asked Questions
Where can I buy TRACO POWER TMPS10115?
You can click on the BUY or RFQ button to purchase TMPS10115 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMPS10115?
You can download the TMPS10115 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMPS10115?
TRACO POWER
