TRACO POWER TML40105 Power Module
The TML series offers ultra-compact, fully encapsulated AC/DC power modules with power ratings of 20 and 40 Watts. These reliable power supplies feature universal input of 90-264 VAC and operate across a broad frequency range of 47-440 Hz. They are designed for space-critical applications in industrial and commercial electronics, supporting various output configurations, including single, dual, and triple outputs. The modules meet stringent EMI standards (EN 55022, FCC) and feature short circuit, overload, overvoltage, and overtemperature protections, ensuring safety and durability in demanding environments. Suitable for PCB or chassis mounting, they are certified under UL/CE safety standards and built with a high-quality plastic resin case.
TRACO POWER TML40105 Power Module Specifications:
- Power ratings: 20W and 40W
- Input Voltage: AC 90-264 VAC, DC 100-375 VDC
- Input Frequency Range: 47-440 Hz
- Output Power: Up to 40W depending on model
- Output Configurations: Single, dual, triple outputs
- Protection Class: II (TML 40 models)
- Efficiency: 74-84%
- Ripple & Noise: <0.7% of Vout + 90 mV (20W), <1% of Vout (40W)
- Input Current at Full Load: Max 860mA for 40W models
- Leakage Current: Max 0.25 mA
- Isolation Voltage: 3000 VAC input/output
- Dimensions: PCB mount models approx. 80-95 mm length, chassis mount approx. 110-130 mm length
- Temperature Range: -25°C to +70°C (20W), -40°C to +60°C (40W)
- Switching Frequency: 100 kHz (20W), 132 kHz (40W)
- MTBF: >200,000 hours
- Certifications: UL/cUL 60950-1, IEC/EN 60950-1, RoHS, Reach
Buy the Traco Power TML40105 – Reliable 40W Power Module for Industrial Applications
Upgrade your electronic systems with the Traco Power TML40105 40W power module. Designed for industrial and commercial electronics, this reliable unit features universal input, multiple output configurations, and high efficiency. Its compact, fully encapsulated plastic case ensures durability and space-saving installation, making it ideal for space-critical applications. Certified under UL and CE safety standards, it provides robust protections including overload, overvoltage, and overtemperature features. Easily mountable on PCB or chassis, this power supply enhances your project's safety and performance through proven technological standards.
Order your Traco Power Series TML40105 today and give your industrial projects dependable power with these compact, high-efficiency modules equipped with comprehensive protections.
