TRACO POWER TMPS05105 Power Module
The TMPS-05 series delivers compact, 5-watt AC/DC power modules suitable for space-constrained applications. These fully encapsulated plastic-cased units are certified for household appliances under EN 60335-1 and meet industrial safety standards, including UL 60950-1. They operate efficiently within -25°C to +70°C, draw less than 300 mW at no load, and feature low ripple, noise, and overvoltage protection. Ideal for low-power circuits, their peak current is 130%, making them suitable for standby modes and segregated circuits in industrial and household environments.
TRACO POWER TMPS05105 Power Module Specifications:
- Input voltage range: AC 85 – 264 VAC, DC 120 – 370 VDC
- Input frequency: 47 – 63 Hz
- Output power max: 5W
- Output voltage options: 3.3V, 5V, 9V, 12V, 15V, 24V, 48V
- Output current max: 1515mA (3.3V), 1000mA (5V), 555mA (9V), 416mA (12V), 333mA (15V), 208mA (24V), 104mA (48V)
- Efficiency: 74% to 85%
- Ripple and noise: up to 60 mVp-p (3.3V/5V models)
- Isolation voltage (Input/Output): 4242 VDC
- Operating temperature: -25°C to +70°C
- Protection: Over-voltage max 190% of Vout, hiccup short circuit protection
- Physical: Plastic resin + fiberglass casing, 19.7g weight
- Switching frequency: 65 kHz
- Certifications: EN 60335-1, UL 60950-1, RoHS, Reach (pending)
- Reliability: MTBF 628,000 hours
Buy the Traco Power TMPS-05 – Reliable Power Modules for Industrial Applications
Order the Traco Power TMPS-05 series online today to ensure reliable, compact power supply solutions for your industrial or household applications. These 5-watt modules are certified for safety standards including EN 60335-1 and UL 60950-1, making them suitable for low-power, space-constrained circuits. With efficiency up to 85%, low ripple, noise, and advanced protection features, they are ideal for standby modes and segregated circuits. Fast and convenient online purchase ensures quick integration into your design, supported by a 3-year warranty for long-term durability.
Get Traco Power TMPS-05 today—compact, efficient, and built for rugged industrial and household power needs.
