TRACO POWER TRI101211 High-Voltage Isolated DC/DC Converter
The TRI 10 series is a high-isolation, regulated 10 Watt DC/DC converter with a compact DIP-24 package, designed for industrial, transportation, and instrumentation applications. It features reinforced isolation capable of withstanding high test voltages up to 9000 VDC for 1s, with an operating voltage of 1000 VAC, along with a high common mode transient immunity of 15 kV/ps. The series offers efficiencies up to 88%, wide input voltage ranges (9-18V, 18-36V, 36-75V), and includes safety certifications IEC/EN/UL 62368-1. Its robust design ensures reliable operation in demanding environments, with protections against overload, overvoltage, and short circuits, plus a 3-year warranty.
TRACO POWER TRI101211 High-Voltage Isolated DC/DC Converter Specifications:
- Input Voltage Range: 9-18 VDC, 18-36 VDC, 36-75 VDC
- Rated Power: 10 Watts
- Isolation Voltage: 7071 VDC for 60s, 9000 VDC for 1s
- Efficiency: Up to 88%
- Operating Temp Range: -40°C to +85°C (derating above +65°C)
- Input Currents: 12 VDC at 960 mA full load, 12 mA no load
- Protection: Overload, Overvoltage, Short Circuit
- Common Mode Transient Immunity: 15 kV/ps
- Certification: IEC 62368-1, UL 62368-1, IEC/EN safety standards
- Dimensions: DIP-24, compact packaging, plastic UL94V-0 rated
- Cooling: Natural convection
- Soldering: Wave soldering at 260°C for 10 seconds
- Housing Material: Plastic
- Isolation Resistance: 10,000 MOhm min at 500 VDC
- Isolation Capacitance: 20 pF max at 100 kHz/1 V
Buy the Buy TracoPower TRI 10 Series Part Number TRI101211 Online
Secure your supply chain with the high-quality TracoPower TRI 10 Series DC/DC converter. Designed for demanding industrial, transportation, and instrumentation uses, it offers reinforced high-voltage isolation tested at 9000 VDC, efficiency up to 88%, wide input voltage ranges, and robust protections against overloads, surges, and short circuits. Compact design with DIP-24 packaging ensures easy integration into your systems. Backed by a 3-year warranty and certified to IEC/EN/UL standards, this converter guarantees reliable, safe, and efficient power conversion for critical applications.
Buy TracoPower TRI 10 Series TRI101211 now and experience unmatched reliability and high efficiency in your industrial and transportation projects.
