TRACO POWER TVN30910 DC/DC Converter
The TVN 3 Series offers ultra low ripple and noise 3 Watt DC/DC converters designed for space-limited applications. Featuring fully regulated outputs, they support multiple input voltage ranges from 4.5V to 75V and provide 1.600 VDC 1/0-isolation. Widely used in industrial, control, and electronics applications, these converters operate reliably between -40°C to +90°C without derating and include features like short circuit protection, no minimum load requirement, and high efficiency up to 83%. Compact SIP-8 packaging ensures easy integration in various electronic systems.
TRACO POWER TVN30910 DC/DC Converter Specifications:
- Input Voltage Range: 4.5-13.2 VDC, 9-18 VDC, 18-36 VDC, 36-75 VDC
- Output Voltage: 3.3 VDC, 5.0 VDC, 9.0 VDC, 15 VDC, 24 VDC, 42 VDC, 48 VDC, 36-75 VDC
- Output Current Max: 700 mA for 3.3 V, 600 mA for 5 V, 333 mA for 9 V, 200 mA for 15 V, 125 mA for 24 V
- Efficiency: Up to 85% depending on model, Wide temperature range from -40°C to +90°C, Fully regulated outputs, 1,600 VDC isolation voltage, No minimum load required, Short circuit protection
- Ripple and Noise: 10 mVp-p typ. with 10 uF capacitor, 15 mVp-p without external components, Start-up time approx. 30 ms, Transient response 500 us
- Physical: SIP-8 package, Copper case, Silicone potting material UL 94V-0, Approximate weight 5.9 g, Dimensions in mm: 13x25x10 mm, Pin pitch 2.54 mm, Temperature ranges -40°C to +90°C operating, -55°C to +125°C storage
- Isolation: 1,600 VDC, Isolation capacitance 1,500 pF, Resistance > 1 GΩ, EMI Compliance: EN 55032, EN 61000-4 series immunity standards, Conducted noise 15 mVp-p typ.
- Environment: Reliable operation in humid conditions, Derating above 75°C at 3.3%/K, Compliance with IEC/EN 60950-1, UL 60950-1, RoHS, Environmental conditions include thermal shock and vibration according to MIL-STD-810F
Buy the Traco Power Series TVN 3 Series DC/DC Converter: TVN30910
Order the Traco Power TVN30910 online today and experience reliable power conversion with ultra low ripple, high efficiency, and a compact SIP-8 package ideal for space-sensitive applications. Designed for industrial control systems and electronics, it features wide input voltage support from 4.5V to 75V, fully regulated outputs, 1,600 VDC isolation, and protection features like short circuit prevention. Easy to integrate, this converter operates seamlessly from -40°C to +90°C, ensuring durability and consistent performance in demanding environments.
Get Traco Power TVN30910 today—built for precision and long-lasting durability in industrial control systems.
