WAGO 806203 3-pole PCB Terminal Block
The WAGO 806-203 is a compact, 3-pole PCB terminal block ideal for a variety of applications requiring secure and efficient connections. Featuring WAGO’s Push-in CAGE CLAMP technology, this terminal block allows for quick and easy termination of both solid and ferruled conductors using a screwdriver. The double-entry design facilitates power supply and potential distribution, streamlining circuit layouts and reducing complexity. Its compact size and robust construction make it suitable for use in a wide range of industrial and commercial applications, including power supplies, control panels, and automation systems. The terminal block is also designed for easy PCB replacement without disrupting looped-through potentials, minimizing downtime and improving maintenance efficiency.
WAGO 806203 3-pole PCB Terminal Block Specifications:
- Nominal Voltage (III/3): 250 V
- Rated Surge Voltage (III/3): 4 kV
- Rated Voltage (III/2): 320 V
- Rated Surge Voltage (III/2): 4 kV
- Nominal Voltage (II/2): 630 V
- Rated Surge Voltage (II/2): 4 kV
- Rated Current: 10 A
- Rated Voltage UL (Use Group B): 300 V
- Rated Current UL (Use Group B): 10 A
- Rated Voltage UL (Use Group D): 300 V
- Rated Current UL (Use Group D): 10 A
- Rated Voltage CSA (Use Group B): 300 V
- Rated Current CSA (Use Group B): 10 A
- Connection Technology: Push-in CAGE CLAMP®
- Actuation Type: Operating tool
- Solid Conductor: 0,2 … 1,5 mm² / 24 … 16 AWG
- Fine-Stranded Conductor: 0,2 … 1,5 mm² / 24 … 16 AWG
- Fine-Stranded Conductor with Insulated Ferrule: 0,25 … 1 mm²
- Fine-Stranded Conductor with Uninsulated Ferrule: 0,25 … 1 mm²
- Strip Length: 9 … 10 mm / 0.35 … 0.39 inch
- Conductor Connection Direction to PCB: 45 °
- Pole No.: 3
- Total Number of Connection Points: 6
- Total Number of Potentials: 3
- Number of Connection Types: 1
- Number of Levels: 1
- Width: 16,5 mm / 0.65 inch
- Height: 23,3 mm / 0.917 inch
- Depth: 19,8 mm / 0.78 inch
- Solder Pin Diameter: 1 mm
- Contact Type (Pluggable Connector): Female connector/socket
- Connector (Connection Type): for PCB
- Mating Direction to the PCB: 90 °
- Color: gray
- Material Group: I
- Insulation Material: Polyamide 66 (PA 66)
- Flammability Class per UL94: V0
- Clamping Spring Material: Chrome nickel spring steel (CrNi)
- Contact Material: Copper alloy
- Contact Plating: tin-plated
- Fire Load: 0.083 MJ
- Weight: 4.1 g
- Limit Temperature Range: -60 … +105 °C
- Product Group: 4 (Printed Circuit)
- Packaging Type: BOX
- Country of Origin: PL
- GTIN: 4045454077075
- Customs Tariff Number: 85369010000
