XP POWER AH08P5 High Voltage DC Converter
The AH Series comprises ultra-miniature DC to high-voltage DC converters known for high voltage miniaturization. Featuring a compact package that occupies less than one-tenth of a cubic inch and a height of only 0.250 inches (6.35 mm), these converters deliver adjustable output voltages from 100 V to 6000 V. The output voltage is directly proportional to the input voltage and maintains linearity. Key features include a turn-on voltage of 0.7 VDC, input-to-output isolation, short circuit protection, a control pin, and no minimum load requirement. Suitable for power management applications, these converters are ideal where space is extremely limited.
XP POWER AH08P5 High Voltage DC Converter Specifications:
- Output Voltage: 100V to 6000V
- Output Current: 15mA
- Input Voltage: 07, 5, 12, 24V
- Turn-On Voltage: 0.7VDC
- Isolation: Input to Output: 500V
- Ripple and Noise: 5%
- Temperature Range: -25°C to +85°C (operating), -55°C to +105°C (storage)
- Dimensions: Height 0.25 inch (6.35mm), Width 0.45 inch (11.43mm), Length varies by model (0.92 to 1.33 inches)
- Construction: Solid vacuum encapsulation, UL 94V-0 rated
- Cooling: Natural convection
- Safety Approvals: UL IEC/UL/C-UL 62368, RoHS 2&3
Buy the XP Power AH Series Ultra-miniature High-Voltage Converter for Industrial Applications
Enhance your projects with the XP Power AH Series high-voltage DC converters. Designed for minimal space requirements, these ultra-compact modules deliver adjustable output voltages up to 6000V. Perfect for electrophoresis, sensor powering, and capacitor charging, they feature input-to-output isolation, short circuit protection, and no minimum load. Easy to integrate with a small footprint of less than one-tenth cubic inch and a height of only 0.250 inches, ensuring optimal performance in tight spaces. Purchase online today for reliable, high-quality power solutions.
Get XP Power AH Series high-voltage converters today—built for precision and long-lasting durability in space-constrained projects.
Frequently Asked Questions
Where can I buy XP POWER AH08P5?
You can click on the BUY or RFQ button to purchase AH08P5 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part AH08P5?
You can download the AH08P5 datasheet or visit the XP POWER website for support.
Who is the manufacturer of AH08P5?
XP POWER
