XP POWER FHSMM06A1FR Medical Chassis Mount Filter
The FHSM single-stage filter is housed in a compact, chassis-mounting metal case designed for medical applications, offering low earth leakage current of 5µA at 250VAC. It features input and output connections via 6.3 x 0.8mm Faston terminals and should be installed close to the mains cable entry point to minimize radiated emissions. Suitable for Type I appliances, all models have a shielded metal body and include a bleed resistor to safely discharge filter capacitors when power is disconnected. These filters are certified with EN60939-2 for passive components and ANSI/UL1283 for EMI filtering. They operate across a wide temperature range from -40°C to +110°C, with full power operation up to +50°C. Available in ratings from 1A to 20A, they are ideal for medical device applications requiring high safety and reliability.
XP POWER FHSMM06A1FR Medical Chassis Mount Filter Specifications:
- Rated Voltage: 250 VAC
- Input Frequency: 400 Hz
- Rated Current: 1A
- Earth Leakage Current: 5 µA
- Temperature Operating Range: -40°C to +110°C
- Protection Class: Type I
- Terminal Type: Faston 6.3 x 0.8mm
- Dielectric Strength: 1500 VAC
- Safety Approvals: EN60939-2, ANSI/UL1283
- Flammability Rating: UL 94 V-0
- MTBF: 22,000 hours (MIL-HDBK-217F at 40°C)
- Weight: 37g
- Shielded metal body for EMI suppression
- Includes bleed resistor for safe capacitor discharge
Buy the XP Power FHSMM06A1FR – Reliable Medical Chassis Mount Filter for Industrial Applications
Discover the trusted performance of the XP Power FHSMM06A1FR medical chassis mount filter, designed for high safety, low leakage, and reliable EMI suppression. Its compact, shielded metal body and wide operating temperature range make it ideal for demanding medical applications. Easily installed near mains entry, it provides peace of mind through certified safety approvals and built-in bleed resistor for safe capacitor discharge. Enhance your equipment’s safety, reduce EMI emissions, and ensure long-term reliability by ordering this high-quality filter online today.
Order your XP Power FHSMM06A1FR medical chassis mount filter today and ensure your medical devices meet strict safety and EMI standards.
