XP POWER ITA1205S DC-DC Converter
The ITA1205S is a compact, high-reliability 1-watt DC-DC converter featuring dual outputs and a SIP package. Operating from -40°C to +105°C, it supports full load at 95°C ambient with 1500 VDC isolation and Class B emissions. Designed for industrial and embedded applications, it offers excellent efficiency, rapid transient response, and continuous short circuit protection. Its small size and robust design make it ideal for space-constrained environments requiring stable power conversion with minimal electromagnetic interference.
XP POWER ITA1205S DC-DC Converter Specifications:
- Input Voltage Range: 5 V (708-132 VDC), 12 V (216-26.4 VDC), 24 V (708-132 VDC)
- Output Voltage: 5 V, 12 V, 15 V, 24 V depending on model
- Output Current: from 7mA to 250mA depending on model and output voltage
- Isolation Voltage: 1500 VDC
- Operating Temperature: -40°C to +105°C with derating at higher temps
- Efficiency: up to 81%
- Dimensions: 0.76 x 0.24 x 0.39 inches (19.5 x 6 x 10 mm)
- Full load operation at 95°C ambient
- Input Ripple: 6 mA pk-pk at 12 pH inductor and 47 μF capacitor
- Surge Voltage: 18 VDC for 1000 ms (12 V models), 30 VDC (24 V models)
- Ripple & Noise: 60 mV pk-pk at 20 MHz bandwidth
- Short Circuit Protection: Continuous with auto-recovery
- Isolation Resistance: 10 MΩ
- Switching Frequency: 40/50 kHz for 5 V, 12-24 V inputs
- Power Density: 4 W/in³
- MTBF: over 36 million hours
- Humidity: 95% non-condensing
- Cooling: Natural convection
Buy the XP Power Series ITA DC-DC Converter: ITA1205S
Order the XP Power ITA1205S online today to secure a compact, high-efficiency power conversion solution. Designed for industrial, embedded, and space-constrained applications, this converter offers excellent EMC performance, broad temperature range, and reliable operation. Its dual outputs, high isolation, and proven durability make it ideal for demanding environments. Enjoy fast shipping, competitive pricing, and dedicated support. Upgrade your power management systems with the trusted quality of XP Power’s ITA series DC-DC converters and ensure stable, efficient energy conversion in your projects.
Buy XP Power ITA1205S now and experience unmatched reliability and performance in compact power solutions.
