XP POWER ITP0312D15 DC-DC Converter
The ITP series provides a compact 3W DC-DC converter module with a wide input voltage range and regulated outputs from 3.3V to 15V. It features a robust encapsulated SIP6 package, high efficiency, and 1.6kVDC input/output isolation. Suitable for industrial applications, it operates across a temperature range of -40°C to +75°C and includes short-circuit protection. The module complies with EN55032 standards and offers remote On/Off control for single-output models, maintaining full power up to +70°C.
XP POWER ITP0312D15 DC-DC Converter Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5-18V, 9-36V, 18-75VDC
- Output Voltages: 3.3V, 5V, 12V, 15V
- Output Current: 700 mA (3.3V), 600 mA (5V), 250 mA (12V), 200 mA (15V)
- Efficiency: Up to 83%
- Isolation Voltage: 1.6kVDC
- Operating Temperature: -40°C to +75°C
- Package: SIP6 encapsulated
- Dimensions: 17.0 x 10.1 x 11.7 mm (0.67 x 0.40 x 0.46 inches)
- Short-circuit protection: Yes
- Remote On/Off: Available for single output models
- Standards: EN55032, UL62368-1, CE
- MTBF: >0.95 million hours
- Warranty: 3 years
Buy the XP Power Series ITP 3W DC-DC Converter: ITP0312D15
Purchase the XP Power Series ITP 3W DC-DC Converter online today to experience reliable power regulation with wide input voltage ranges and high efficiency. Designed for industrial applications, this compact module offers regulated outputs from 3.3V to 15V, with robust encapsulation and 1.6kVDC isolation. Its operating temperature range of -40°C to +75°C ensures durability in harsh environments while providing short-circuit protection and remote On/Off control. Ensure seamless integration and maximum uptime for your electronics by buying online now.
Order your XP Power Series ITP 3W DC-DC Converter today and ensure reliable power regulation for your industrial projects.
Frequently Asked Questions
Where can I buy XP POWER ITP0312D15?
You can click on the BUY or RFQ button to purchase ITP0312D15 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0312D15?
You can download the ITP0312D15 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0312D15?
XP POWER
