XP POWER ITP0348S3V3 DC-DC Converter Module
The ITP series is a compact 3W DC-DC conversion module designed for cost-effective applications. It features a wide input voltage range and regulated output voltages from 3.3V to 15V with 1% regulation accuracy. Operating across an industrial temperature range from -40°C to +75°C, it offers robust encapsulation and high efficiency. Key features include regulated single and dual outputs, a 4:1 input voltage range (4.5 to 18V, 9 to 36V, or 18 to 75V), an ultra-compact SIP6 package, 1.6kVDC input/output isolation, compliance with EN55032 standards, short-circuit protection, and remote on/off control for single output models. Full power is maintained up to 70°C.
XP POWER ITP0348S3V3 DC-DC Converter Module Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5-18V, 9-36V, 18-75V
- Output Voltages: 3.3V, 5V, 12V, 15V (regulated to 1%)
- Input/Output Isolation: 1.6kVDC
- Efficiency: Up to 84%
- Operating Temperature Range: -40°C to +75°C
- Package: SIP6 ultra-compact
- Short-circuit protection: Yes
- Remote On/Off: Yes (single output models)
- Dimensions: 0.67 x 0.40 x 0.46 inches (17.0 x 10.1 x 11.7 mm)
- MTBF: >0.95 million hours (MIL-HDBK-217F at +25°C)
- Certifications: EN55032, UL62368-1, CE, EN61000-4-2, EN61000-4-8
Buy the XP Power ITP0348S3V3 – Reliable DC-DC Converter for Industrial Applications
Purchase the XP Power ITP0348S3V3 online today to benefit from a reliable 3W DC-DC conversion solution suitable for industrial environments. With wide input voltage ranges from 4.5V to 75V, regulated outputs from 3.3V to 15V, and an industrial temperature range from -40°C to +75°C, this module ensures robust and efficient performance. Its encapsulated SIP6 package provides durability and space savings, while features like 1.6kVDC isolation, short-circuit protection, and remote on/off make installation easy. Ensure your industrial applications operate smoothly with this dependable power module—shop now for swift delivery.
Order your XP Power Series ITP0348S3V3 today and give your projects the dependable power they deserve, ensuring stable operation across industrial temperature ranges.
Frequently Asked Questions
Where can I buy XP POWER ITP0348S3V3?
You can click on the BUY or RFQ button to purchase ITP0348S3V3 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0348S3V3?
You can download the ITP0348S3V3 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0348S3V3?
XP POWER
