XP POWER ITQ4809SA DC-DC Converter
The ITQ series is an isolated 6W DC-DC converter featuring fully regulated single and dual outputs with a wide 4:1 input voltage range. It operates across temperatures from -40°C to 100°C, provides 1500VDC isolation, and requires no minimum load. The product includes a remote On/Off function, making it suitable for power management, industrial, and safety applications. Its compact SIP 8 package ensures efficiency and reliability in demanding environments, with UL safety approval and optional 3000VDC isolation for enhanced safety measures.
XP POWER ITQ4809SA DC-DC Converter Specifications:
- Power: 6 Watts
- Input Voltage Range: 18V to 75V AC/DC, nominal 24V
- Output Voltage: 3.3V to 24V DC, regulated
- Isolation: 1500VDC, optional 3000VDC with suffix '-H'
- Operating Temperature: -40°C to 100°C, derated at high temp
- Case Material: SIP 8 package
- Remote On/Off Control: Yes, turns off if 2-4 mA applied
- Efficiency: up to 87%
- Ripple & Noise: 5 mV pk-pk at 20 MHz bandwidth
- Surge Voltage: 50V AC for 100ms (input)
- Safety Certification: UL60950-1, UL62368-1, CSA C22.2 No. 60950-1, No. 62368-1
- Dimensions: 0.86 x 0.36 x 0.44 inches (21.9 x 9.2 x 11.1 mm)
- Temperature Coefficient: 0.02 %
- Humidity Tolerance: 5% RH non-condensing
- Cooling: Natural convection
- Maximum Capacitive Load: 4700 μF (varies by model)
Buy the XP Power ITQ4809SA – Reliable DC-DC Converter for Industrial Applications
Get the XP Power ITQ4809SA compact 6W DC-DC converter online today and enjoy fast delivery, robust safety certifications, and excellent performance in industrial environments. Its regulated single and dual outputs, wide input voltage range, and remote On/Off control make it ideal for demanding power management applications. Suitable for industrial, safety, and automation systems, this converter provides high efficiency, 1500VDC isolation, and no minimum load requirements. Secure your power solutions now with our trusted online purchase options, ensuring quality and reliability every time.
Buy XP Power ITQ4809SA now and experience unmatched reliability and performance in power conversion for industrial and safety systems.
