XP POWER JTE0624S12 Power Supply Module
The JTE0624S12 is a high-reliability power supply module offering a 6 W output with an extensive input voltage range of 9-36 VDC for 24 V models and 18-75 VDC for 48 V models. Its compact DIP-24 plastic case ensures easy installation, with optional metal casing available. Capable of operating in temperatures from -40°C to +100°C, it includes features like overvoltage lockout, overload and short circuit protection, and high insulation voltage of 1500 VDC. Designed for industrial applications, it has efficient performance, low ripple, and noise, making it suitable for demanding environments requiring stable power conversion.
XP POWER JTE0624S12 Power Supply Module Specifications:
- Input Voltage Range: 9-36 VDC for 24 V models, 18-75 VDC for 48 V models
- Input Filter: Pi network with 20 mA pk-pk through 12 HH inductor and 4.7 UF capacitor
- Input Surge: 50 VDC for 100 ms (24 V model), 100 VDC for 100 ms (48 V model)
- Operating Temperature: -40°C to +100°C, derates above 60°C
- Output Voltage: 24 VDC
- Output Voltage Balance: +2% max for dual output models, ±2% max for single output
- Initial Set Accuracy: ±2%
- Minimum Load: No minimum load required
- Line Regulation: 1.2% max (single), 5% max (dual)
- Load Regulation: 20.5% max
- Ripple & Noise: 80 mV pk-pk (100 mV for D24 models), measured with 1F ceramic across output
- Transient Response: <3% deviation, recovery within 300 ps for 25% load change
- Overload Protection: Trip & restart (Hiccup mode), auto recovery
- Short Circuit Protection: Yes, auto recovery
- Maximum Capacitive Load: 135% - 185% of Full Load
- Temperature Coefficient: +0.02/°C max
- Efficiency: Up to 85%
- Isolation Voltage: 1500 VDC input to output, 1000 VDC input to case, 1000 VDC output to case
- Isolation Capacitance: 1000 pF typical
- Switching Frequency: 330 kHz typical
- Power Density: High, suitable for compact designs
- MTBF: >800,000 hours at 25°C (GB)
- Environmental: -40°C to +100°C operating temperature, natural convection cooling, up to 95% humidity, non-condensing
- EMC & Safety: Meets EN55022 Class A, UL60950-1, CSA C22.2 No.60950-1, IEC standards
Buy the Reliab Power Supply 6 Watts Industrial Power Modules
Upgrade your industrial power systems with the reliable JTE0624S12 power supply module. Offering stable output, extensive input voltage compatibility, and high efficiency, this module ensures your equipment runs smoothly in harsh environments. Its robust design features comprehensive protection against overvoltage, overload, and short circuits. With a wide temperature operating range and high insulation voltage, it is perfect for demanding industrial applications. Purchase online now and experience dependable power performance that enhances your project's operational stability and safety.
Order your Reliab Series JTE0624S12 power supply today and ensure stable, efficient power delivery for demanding industrial projects.
