BROADCOM HSMRC150 High Brightness Blue LED
The HSMR-C150 is a high-performance blue Chip LED featuring a diffused lens, made from InGaN material. It offers high brightness and efficient emission at a wavelength of 470nm, providing a unique hue for color differentiation. The LED comes in a top-emitting package with a wide viewing angle, making it suitable for direct backlighting applications and use with light pipes. It is compatible with IR soldering and is binned by both color and intensity. Designed with a small, industry-standard footprint, it is ideal for LED lighting, signaling, and industrial applications. As a Class 1A ESD-sensitive device, proper handling precautions are required.
BROADCOM HSMRC150 High Brightness Blue LED Specifications:
- Wavelength: 470 nm
- Color: Blue
- Luminous Intensity: 145-155 mcd (Typ. 145), Min. 45
- Peak Wavelength: 520 nm
- Dominant Wavelength: 527 nm
- Viewing Angle: 140°
- Package Type: Top emitting, diffused optics
- Size: 3.50 x 1.88 x 1.27 mm
- Package Compatibility: IR soldering, binned by color and intensity
- Storage Temperature: -40 to +85°C
- Operating Temperature: -40 to +85°C
- Power Dissipation: 78 mW
- Reverse Voltage: 5 V
- Forward Voltage: Max 3.9 V at 20 mA
- Class: 1A ESD sensitive, handle with care
Buy the Avago HSMR-C150 – Reliable Blue LED for Industrial Applications
Discover the high-brightness blue LED designed for industrial lighting, signaling, and backlighting applications. The HSMR-C150 features diffused optics, industry-standard footprint, and compatibility with IR soldering. It provides excellent performance with a peak wavelength of 520 nm, luminous intensity of up to 155 mcd, and a wide 140° viewing angle, making it ideal for microdisplays, message panels, and front panels. Ensure proper handling as it is a Class 1A ESD-sensitive device. Purchase online today for reliable, efficient LED solutions!
Buy Avago HSMR-C150 now and experience unmatched reliability and performance in LED lighting and industrial signaling.
