INFINEON TLE5014C16DXUMA1 angle sensor
The TLE5014D is a dual die GMR-based angle sensor designed for automotive safety applications. Featuring two identical, galvanically decoupled sensors in one package, it provides redundant 12-bit absolute angle measurements with maximum 1° error over lifetime and temperature. It supports interfaces like SENT, SPC, and PWM, includes EEPROM configuration, and complies with ASIL-D safety standards. Ideal for high-reliability angular position sensing, it offers internal safety mechanisms with diagnostic coverage over 97%, making it suitable for safety-critical automotive systems requiring high functional safety and precision.
INFINEON TLE5014C16DXUMA1 angle sensor Specifications:
- Sensor Type: GMR-based dual die angle sensor
- Output Resolution: 12-bit absolute angle value
- Maximum Angle Error: 1° over lifetime and temperature
- Interfaces Supported: PWM, SPC, SENT (SAE J2716-2010)
- Temperature Range: -40°C to 125°C (Grade 1, automotive qualified)
- Voltage Range: High voltage and reverse polarity capability
- Internal Safety: Diagnostic coverage >97% for each channel
- Memory: EEPROM for configuration including zero angle and customer ID
- Configuration: Pre-configured derivatives with locked interfaces for safety
- Dimensions: PG-TDSO-16 package with footprint as per datasheet dimensions
- Compliance: Automotive safety standards (ASIL-D), RoHS, halogen free
- ESD Protection: Up to 4 kV HBM, 2 kV CDM
- Package Level: MSL 3, suitable for reflow soldering according to JEDEC J-STD-020E
- Application: Automotive motor control, angular position sensing, safety systems
- Reliability: Designed for high safety integrity and fault detection
- Safety Features: Internal safety mechanisms, diagnostic coverage, redundant channels
Buy the Buy Infineon TLE5014D Dual Die Angle Sensor Part Number TLE5014C16DXUMA1 Online
Purchase the Infineon TLE5014D dual die GMR-based angle sensor online for automotive safety and control applications. This highly reliable device features two independent channels providing absolute position measurement with maximum 1° error. It supports multiple interfaces including SENT, SPC, and PWM, and includes built-in EEPROM for configuration and customer ID storage. Designed for safety-critical systems, it offers diagnostic coverage above 97%, fitting strict automotive safety standards like ASIL-D. Order now for fast delivery and enhance your safety and control projects with this top-grade angle sensing device.
Order your Infineon TLE5014D safety-rated dual die angle sensor today and ensure reliable high-accuracy angular position detection for automotive safety systems.
Frequently Asked Questions
Where can I buy INFINEON TLE5014C16DXUMA1?
You can click on the BUY or RFQ button to purchase TLE5014C16DXUMA1 from an authorized INFINEON distributor.
How do I troubleshoot issues or seek technical support for part TLE5014C16DXUMA1?
You can download the TLE5014C16DXUMA1 datasheet or visit the INFINEON website for support.
Who is the manufacturer of TLE5014C16DXUMA1?
INFINEON
