MOLEX 10321051 Wire-to-Board Connector
The SPOX Wire-to-Board Header is a 5.08mm pitch connector designed for reliable electrical connections in industrial and electronic applications. Featuring a vertical orientation with a friction lock, it supports 5 circuits and can withstand up to 30 mating cycles. Made from durable nylon resin with tin-plated brass contacts, it operates within a temperature range of -40°C to +105°C. Certified under UL and CSA standards, this connector ensures secure, high-quality performance in various electrical and power distribution setups.
MOLEX 10321051 Wire-to-Board Connector Specifications:
- Pitch: 5.08mm
- Number of Circuits: 5
- Maximum Mating Cycles: 30
- Contact Material: Brass
- Contact Plating: Tin
- Resin Material: Nylon
- Operating Temperature Range: -40°C to +105°C
- Voltage Rating: 250V
- Current per Contact: 7.0A
- First Mate / Last Break: No
- Color - Resin: Natural
- Durability: 30 mating cycles
- Flammability Rating: 94V-2
- Locking Feature: Friction Lock
- Orientation: Vertical
- PCB Tail Length: 3.60mm
- PCB Thickness - Recommended: 1.60mm
- Packaging: Bag
- RoHS & REACH Compliant
- Through Hole Mounting
- Rated for UL and CSA certification
Buy the Molex 0010321051 – Reliable Wire-to-Board Connector for Industrial Applications
Purchase the Molex 0010321051 wire-to-board connector online today and enjoy high reliability with a 5.08mm pitch, 5 circuits, and UL/CSA certification. This vertical connector features a friction lock for secure mating and withstands up to 30 mating cycles. Crafted from durable nylon resin with tin-plated brass contacts, it ensures excellent performance across a temperature range of -40°C to +105°C. Perfect for power distribution, automation, and electronic systems, this connector is essential for robust industrial and electronic applications.
Buy Molex 0010321051 now and ensure secure, durable power and signal connections with this high-quality wire-to-board header designed for industrial and electronic use.
Frequently Asked Questions
Where can I buy MOLEX 10321051?
You can click on the BUY or RFQ button to purchase 10321051 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 10321051?
You can download the 10321051 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 10321051?
MOLEX
