MOLEX 1053071202 Nano-Fit Power Connector
The MOLEX 105307-1202 Nano-Fit Power Connector is a receptacle housing designed for robust wire-to-board connections. This 2-circuit connector utilizes a 2.50mm pitch and is manufactured with a black nylon resin, ensuring durability and resistance to environmental factors. It is TPA capable and features keyed and locked mating options for secure connections. Suitable for applications requiring reliable power transmission, this connector is a key component in various electronic assemblies.
MOLEX 1053071202 Nano-Fit Power Connector Specifications:
- Overview: Nano-Fit Power Connectors
- Description: Nano-Fit Receptacle Housing, TPA Capable, 2.50mm Pitch, Single Row, 2 Circuits, Black
- Series: 105307
- Circuits (maximum): 2
- Color - Resin: Black
- Flammability: 94V-0
- Gender: Receptacle
- Glow-Wire Compliant: No
- Keying to Mating Part: Yes
- Lock to Mating Part: Yes
- Material - Resin: Nylon
- Net Weight: 0.310/g
- Number of Rows: 1
- Packaging Type: Bag
- Panel Mount: No
- Pitch - Mating Interface: 2.50mm
- Pitch - Termination Interface: 2.50mm
- Polarized to Mating Part: Yes
- Temperature Range - Operating: -40°C to +105°C, -40°C to +115°C
- Current - Maximum per Contact: 6.5A
- Application: Wire-to-Board
- Operating temperature: -40#C to +105#C (tin), -40#C to +115#C (gold)
