OMEGA PX3005030AI industrial pressure transmitter
The OMEGA PX3005 pressure transmitter combines compact design with high accuracy, featuring a rugged 316 stainless-steel enclosure rated IP67, suitable for washdown environments. It offers a 5-digit backlit LCD for clear process variable display and adjustable zero/span for precise calibration. Designed for industrial use, it supports ranges from 1 psi to 15,000 psi, with configurable measurement units and 4-20 mA output. Its MEMs piezoresistive sensors ensure dependable performance across diverse process and fluid monitoring applications in automation and hydraulic systems.
OMEGA PX3005030AI industrial pressure transmitter Specifications:
- Environmental Rating: IP67
- Enclosure Material: 316 Stainless Steel
- Display: 5-digit backlit LCD
- Accuracy: +/- 0.2% URL
- Power Supply: 10.5 to 55 VDC
- Output Signal: 4-20mA Two-wire
- Media Compatibility: Fluids and gases with 316 SS and FKM
- Operating Temperature: -20°C to 70°C
- Storage Temperature: -40°C to 85°C
- Media Temperature: -40°C to 120°C
- Electrical Connection: 4 pin male M12
- Process Connection: 1/4''-18NPT (M)/316 SS
- Response Time: 200 ms
- Vibration Resistance: 20g (5-2000Hz)
- Power Consumption: 500mW
- Rangeable: Zero and span from -100% to 100% FS URL
- Turndown Ratio: Up to 2 based on set span and nominal range
- Over Range Limit: As specified for each range
- Calibration Report: Included
- Mounting: Any position with correction possible via PV=0 reset
Buy the Omega Series PX3005 Pressure Transmitter Industrial and Hydraulic Sensor: PX3005030AI
Purchase the Omega PX3005 pressure transmitter online today to enhance your process automation and hydraulic system monitoring. This robust device offers high accuracy, configurable measurement ranges from 1 to 15,000 psi, and is built with corrosion-resistant 316 stainless steel. Its IP67-rated enclosure ensures durability in washdown environments, while the LCD display and calibration report enable easy setup and maintenance. Ideal for controlling and monitoring pressures in pumps, compressors, and tank applications, this transmitter provides dependable performance and flexible configuration for your industrial needs.
Order your Omega PX3005 pressure transmitter today and ensure precise, reliable pressure monitoring in your industrial systems with these durable, configurable sensors.
Frequently Asked Questions
Where can I buy OMEGA PX3005030AI?
You can click on the BUY or RFQ button to purchase PX3005030AI from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PX3005030AI?
You can download the PX3005030AI datasheet or visit the OMEGA website for support.
Who is the manufacturer of PX3005030AI?
OMEGA
