TRACO POWER TEL101222 DC-DC Converter
The TEL 10 series is a compact 10 Watt DC/DC converter housed in a DIP-16 metal casing, optimized for space-critical applications. It features a wide 2:1 input voltage range, high efficiency up to 88%, and a compact design measuring only 16 pins. The converter offers excellent thermal performance with operating temperatures up to +70°C at full load. It includes built-in input filtering, short circuit protection, and complies with EMI standards EN 55032 class A, making it suitable for industrial electronics, instrumentation, and IT applications. Its robust design ensures reliable power conversion in confined environments.
TRACO POWER TEL101222 DC-DC Converter Specifications:
- Power: 10 Watt
- Input Voltage Range: 9-36 VDC or 18-76 VDC depending on model
- Output Voltage Options: 3.3 V, 5.1 V, 12 V, 15 V, 24 V, -12 V, -15 V
- Output Current: Up to 700 mA
- Efficiency: Up to 88%
- Operating Temperature Range: -40°C to +85°C (with derating up to +70°C at full load)
- Isolation Voltage: 1800 VDC (input to output)
- Ripple & Noise: 72-96 mVp-p depending on model & output
- Surge Voltage: 25-100 VDC depending on model
- Protection: Short circuit, input under-voltage lockout, automatic recovery
- Dimensions: 16 pins, approx. 15.24 mm x 15.24 mm x 10 mm (0.6
Buy the Traco Power TEL 10 – Reliable DC-DC Converter for Industrial Applications
Purchase the Traco Power TEL 10 series 10 Watt DC-DC converter online today for reliable, high-efficiency power conversion. Its compact design, with a DIP-16 metal case, makes it ideal for space-sensitive applications like industrial control, instrumentation, and IT systems. Featuring a wide input voltage range, overall efficiency up to 88%, and excellent thermal performance, this converter also provides built-in input filtering, short circuit protection, and exceeds EMI standards EN 55032 class A. Get dependable power with easy online ordering and fast delivery for your critical projects.
Order your Traco Power Series TEL 10 10 Watt DC-DC Converter today and ensure dependable power supply for your industrial and instrumentation projects.
Frequently Asked Questions
Where can I buy TRACO POWER TEL101222?
You can click on the BUY or RFQ button to purchase TEL101222 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TEL101222?
You can download the TEL101222 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TEL101222?
TRACO POWER
