TRACO POWER TPP15124J Medical Power Supply
This 15-watt power supply is ideal for medical applications, offering high efficiency up to 88.5%, reinforced insulation, low leakage current under 75 pA, and full compliance with IEC 60601-1 standards. It features a compact design measuring 1.1” x 2.8”, operates from 85-264 VAC, and supports a wide temperature range from -40°C to +70°C with derating up to 85°C. Suitable for medical devices, it includes short circuit protection, overvoltage protection, and complies with EMC standards for medical environments. Its robust design ensures reliable power delivery and safety in critical healthcare settings.
TRACO POWER TPP15124J Medical Power Supply Specifications:
- Power: 15W
- Output Voltage Range: 3.3 VDC to 48 VDC
- Rated Output Voltage: 3.3 V, 5 V, 9 V, 12 V, 15 V, 24 V, 36 V, 48 V
- Output Current: 1000 mA to 4000 mA depending on model
- Input Voltage: 85-264 VAC, 120-370 VDC (no certification)
- Input Frequency: 47-63 Hz
- Efficiency: Up to 88.5%
- Operating Temperature: -40°C to +70°C (derates to 85°C at 50% load)
- Temperature Coefficient: ~0.02%/K
- Protection: Short circuit, overvoltage, automatic recovery
- Leakage Current: <75 pA
- Isolation Voltage: 5,657 VDC (input to output), 21,121 VDC (input to case)
- Certification: IEC 60601-1, UL 62368-1, EN 60601-1, EN 62368-1
- Certifications: Medical device standards, 2x MOPP internal reinforced insulation
- Dimensions: 1.1” x 2.8” (28 mm x 71.7 mm)
- Weight: 48 g
- Compliance: EMC IEC 60601-1-2 edition 4, EN 55011, FCC Part 15 and 18 class B
- Altitude: Up to 5000 m operating altitude
- Protection Class: Class II reinforced insulation
- Working Voltage: 250 VAC
Buy the Traco Power TPP 15-124J – Reliable Medical Power Supply for Healthcare Devices
Purchase the Traco Power TPP 15-124J online today and ensure your healthcare devices operate safely and efficiently. This high-quality, 15-watt power supply meets international medical standards with reinforced insulation, low leakage current, and excellent efficiency up to 88.5%. Its compact size fits seamlessly into medical equipment, providing stable power from 85-264 VAC with full compliance to IEC 60601-1 and EMC standards for medical environments. Enjoy quick, secure online ordering and benefit from a reliable power solution tailored for healthcare applications.
Buy Traco Power TPP 15-124J now and experience unmatched reliability and performance in medical device applications.
Frequently Asked Questions
Where can I buy TRACO POWER TPP15124J?
You can click on the BUY or RFQ button to purchase TPP15124J from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TPP15124J?
You can download the TPP15124J datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TPP15124J?
TRACO POWER
