TRACO POWER TMR32412 DC/DC Converter Module
The TMR Series DC/DC converters provide reliable 3W power with a wide 2:1 input voltage range and regulated outputs, suitable for compact and space-critical applications across industrial electronics, communication, and instrumentation. Featuring high efficiency up to 85%, remote On/Off control, and continuous short circuit protection, these modules operate from -40°C to +85°C. Encased in a small SIP-8 package with an ultra-compact footprint, they ensure robust electrical insulation of 1500 VDC or 3000 VDC, making them ideal for demanding environments requiring dependable power conversion.
TRACO POWER TMR32412 DC/DC Converter Module Specifications:
- Power: 3W
- Input Voltage Range: 45-90 VDC, 18-36 VDC, 9-18 VDC, etc.
- Output Voltage Options: 3.3V, 5V, 12V, 15V, 24V, 36V
- Output Current: 200-700mA depending on model
- Efficiency: up to 85%
- Isolation Voltage: 1500 VDC or 3000 VDC (with suffix -HI)
- Operating Temperature: -40°C to +85°C
- Case Material: Silicone, UL 94V-0 rated plastic
- Dimensions: 20 mm x 10 mm x 8.5 mm
- Regulation: 0.2% max. input variation, 1-3% load variation
- Ripple & Noise: 50 mVp-p max.
- Short Circuit Protection: Continuous, automatic recovery
- Remote On/Off: Yes
- Weight: 48 g
- Compliance: IEC/EN 60950-1, UL 60950-1, RoHS
Buy the TRACOPOWER TMR 3 Series – Reliable DC/DC Converters for Industrial Applications
Order the TRACOPOWER TMR 3 Series voltage regulators online now to ensure reliable, high-efficiency power supply for your industrial, communication, or instrumentation systems. These compact DC/DC modules offer robust electrical insulation, wide input voltage ranges, and protected features like short circuit protection and remote On/Off control. Their small footprint and operate from -40°C to +85°C make them ideal for space-constrained applications. Acquire these proven power conversion solutions online today for dependable performance in demanding environments.
Get TRACOPOWER TMR 3 Series today—built for precision and long-lasting durability in space-critical environments.
Frequently Asked Questions
Where can I buy TRACO POWER TMR32412?
You can click on the BUY or RFQ button to purchase TMR32412 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part TMR32412?
You can download the TMR32412 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of TMR32412?
TRACO POWER
