TRACO POWER THB32423 DC/DC Converter
The THB 3 series are high-performance, regulated DC/DC converters housed in a DIP-24 package. They feature supplementary and reinforced insulation, with an isolation voltage of 4800 VACrms, suitable for demanding applications like medical, industrial, and transportation systems. These converters operate efficiently from -40°C to +85°C, include internal EMI filters to meet EN 55022 Class A, and provide over-voltage protection. Their robust design ensures high reliability, long lifetime, and compliance with safety standards such as IEC 60601-1 and IEC 60950-1, making them ideal for safety-critical uses.
TRACO POWER THB32423 DC/DC Converter Specifications:
- Input Voltage Range: 3 VDC to 36 VDC, 5 VDC to 48 VDC models available
- Output Voltage: 3 V, 12 V, 15 V, 24 V, 36 V, 75 VDC options
- Output Current: 600 mA to 250 mA depending on model
- Efficiency: Up to 84%
- Isolation Voltage: 4800 VACrms, rated for 1000 Vrms working voltage
- Temperature Range: -40°C to +85°C
- Ripple and Noise: 100-150 mVpk-pk
- Protection: Over-voltage, short-circuit, automatic recovery
- Size: DIP-24 package, weight approximately 13 g
- Certifications: IEC 60601-1, IEC 60950-1, UL 60950-1, EN 60601-1
- Operating Humidity: Up to 95% RH, Non-condensing
- Soldering Temperature: Max 265°C for 10 sec.
- Switching Frequency: Approx. 150 kHz
- Input Protection: Recommended external fuse up to 20A depending on input voltage
- Leakage Current: 2 pA at 240VAC
- Environmental: RoHS compliant, supporting international safety standards
Buy the Buy TRACOPOWER THB Series 3 Watt Part Number THB32423 Online
Purchase the TRACOPOWER THB 3 Series 3 Watt DC/DC converter online today to ensure your devices are powered reliably and safely. With reinforced insulation, wide temperature operation from -40°C to +85°C, and internal EMI filters meeting EN 55022 Class A standards, this converter guarantees high efficiency and long-term dependability. Ideal for medical, industrial, and transportation applications, it features over-voltage protection, automatic short-circuit recovery, and compliance with international safety certifications like IEC 60601-1 and IEC 60950-1. Get this durable and compact converter now for seamless integration into your systems.
Order your TRACOPOWER THB 3 Series high-reliability DC/DC converter today and ensure your industrial or medical projects meet top safety standards.
Frequently Asked Questions
Where can I buy TRACO POWER THB32423?
You can click on the BUY or RFQ button to purchase THB32423 from an authorized TRACO POWER distributor.
How do I troubleshoot issues or seek technical support for part THB32423?
You can download the THB32423 datasheet or visit the TRACO POWER website for support.
Who is the manufacturer of THB32423?
TRACO POWER
